Full Automatic Straight Line Wire Drawing Machine for Nail Making/Wire Binding/Barbed Wire
| US$50,000.00-80,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
LM-LXJ012
Type
LZ Straight-Line Metal Drawing Machine
Usage
Wire, Rope Wire, Prestressed Steel Wire, Standard Parts
Metal Material
Iron
Outlet Diameter
6.5-24mm
Max.Inlet Wire Dia.
10mm
Block Dia.
Customizable
Max. Number of Block
11
Certification
ISO
Condition
New
Core Components
Gear, Motor, PLC
Place of Origin
China
Weight
18000
Key Selling Points
High Productivity
Drawing Speed
12-18 M/Min
Voltage
Customized
Selling Units
Single Item
Applicable Industries
Building Material Shops, Manufacturing Plant, Cons
Transport Package
Standard Marine Packing
Specification
customizable
Trademark
liming
Origin
Hebei
Production Capacity
20set/1year
Packaging & Delivery
Package Size
1000.00cm * 100.00cm * 120.00cm
Package Gross Weight
6000.000kg
Product Description
Φ6.0mm Raw material→ High pay-off frame→ Shelling and Rust removal(Derusting machine)→LZ6/560 Straight Line Wire Drawing Machine→Tension device →Wire take-up machine
| Model | Unit | LM400 | LM560 | LM600 | LM800 |
| Capstan diameter | mm | 400 | 560 | 600 | 800 |
| Drawing dies | Times | 9 | 9 | 9 | 9 |
| Inlet wire diameter | mm | Φ2.5-4.5 | Φ5.5-6.5 | 6.5-8.0 | 8.0-10 |
| Outlet wire diameter | mm | Φ0.8-1.4 | Φ1.6-2.0 | Φ2.0-3.0 | Φ2.8-3.5 |
| Drawing speed | m/s | 12-18 | 10-15 | 8-12 | 8-10 |
| Total reduction rate | % | 90.32 | 90.53 | 90.53 | 90.53 |
| Motor power | Kw | 7.5-15 | 22-37 | 22-37 | 37-75 |
Certifications
After Sales Service
FAQ
Q: Are you a trading company or manufacturer?
A: Our company is a factory integrating production and sales. We can provide competitive prices and services.
Q:Where is your factory located?
Our factory is located in No.3 Road, Botou Development Zone, Cangzhou City, Hebei Province.The nearest airport is Beijing airport ,Tianjin airport or Shijiazhuang airport. We can pick you up from city.
Q: Can your company send your engineers to my country for machine installation, worker training?
A: Yes, our engineers went to more than 60 countries before. They are very experienced.
Q: What's the guarantee time for your machines?
A: Our guarantee time is 2 years since the machine was installed in your factory.
Q: Can you export and supply the customs clearance documents we need?
A: We have much experience for exporting. And we can supply the CE certificate, Form E, certificate of origin etc, your customs clearance will be no problem.
