Factory Price Automatic Concrete Qunfeng Cement Block Machine Curb Stone Making Qf800

Factory Price Automatic Concrete Qunfeng Cement Block Machine Curb Stone Making Qf800

US$51,000.00-100,000.00 1 Set (MOQ)

Basic Info.

Model NO.
QF800
Automatic Grade
Automatic
Type
Concrete Block
Method
Hydraulic Pressure
Processing
Brick Production Line
Product
Brick
Brick Raw Material
Sand, Stone, Cement, Water
Automation
Automatic
Tolerance
0.2mm
Condition
New
Transport Package
Standard Packing
Specification
3000× 2090× 3000mm
Trademark
QUNFENG
Origin
Fujian, Chian
HS Code
847480
Production Capacity
500set/Year

Product Description

Product Description

Features
This machine has the feature of easy operation, excellent products quality, stable performance and low operating cost, it can satisfy the various production requirements, like the baking-free bricks, permeable paver, hollow blocks, curb stones and so on. And the height of products also can be heightened according to customer's requirements; the maxium height of the blocks can be 300mm.
1) The unique arch beam demoulding structure ensure the accurate demoulding requirements, which avoid the damage to blocks and easy to maintain and adjust.
2) The advanced percussive vibration system has better vibration effect which can also reduce the shock to the framework , to ensure the machine with long lifespan
3) The feeding cart is driven by gearbox, which can reduce the cycle time and improve the production efficiency.
4) Forming machine is customized to satisfy customer's requirement, the max. Height of product can reach 300mm
Technical data:

Dimension 3000×2090×3000mm
Rating pressure 21MPa
Vibration Table vibration
Vibration frequency 2800 - 4500r/min
Pallet size 1100×620mm
Cycle time 11-25sec.
Power 41kW
