Non-Woven Polyester Fabric Soft Wadding Production Line

Product Description

Nonwoven Wadding Production Line Factory Directly Supply
Function
Short process step: pre opener-fine opening machine-feeding machine-carding machine -cross lapper-oven--winder and cutting machine
Main technical specifications:
1. Mach. synthetic winterizer width: 3200mm
2. Sintepon weight: 80-300g / sq.m
3. Productivity: 120kg / hour (using 6D fiber and a density of 300g / m²), 70-80kg / hour (using 6D fiber and a density of 100g / m).
4. The consumption of the furnace gas: 15cc / hour (after heating 9-10cub / hour) (gas pressure in the pipe 50Kpa, gas pressure in the burner 5Kpa)
5. Line power: 140kW (90kW after warming up)
6. Fiber used: any polyester
7. Attendants: 3-5 people / shift
Structure
Crank case complete with a vertical balance system
Central oil lubrication circulation and cooling system complete with pressure and temperature alarm systems
Magnesium alloy/PU combined needle board locked firmly by lock-bolt or air tube;multi random computer needling methods for needle board
Chrome plate delivery rollers with carved or patterned surface
Auto top dead center controlled stop
Applications:
Nonwoven Wadding Production Line technology process is the very common and prevailing process in the nonwoven industrial.
With diverse machine combination and designs, Nonwoven Wadding Production Line is applicable for producing various felt, carpet, geotextile, shoe lining, filtration material, substrate layer for synthetic leather and asphalt felt, and other hundreds of innovative nonwoven products.
1. High capacity: up to 1000kg/h
2. This machine line can process 100% long length fiber up to 120mm
3. Enclosed chamer to maintain a negative pressure which can control the airflow properly.
4.Enclosed cover for proper protection and easy maintenance

Technical Parameter:

Machine width:	1500-8000mm
Needle density:	4000-7000s/m
Needle frequency:	100-700RPM for middle speed,1000-1500RPM for high speed
Needle stroke:	30-60mm
Capacity:	100kg/h-1000kg/h
Available raw material:	PP, PET, Polymide, fiberglass, Carbon fiber, Cotton, Jute, etc
