5-10km Three Coordinate Phased Array Low Altitude Surveillance Radar

5-10km Three Coordinate Phased Array Low Altitude Surveillance Radar

US$205,479.00
1-9 Pieces
US$136,986.00
10+ Pieces

Basic Info.

Model NO.
L5000
Application
Home, Communication Electronic Products, Industry, Special Equipment, Traffic
Usage
Auto
Certification
ISO
Pitch Range
30°
Azimuth Range
360°
Distance Blind Zone
≤ 150m
Operating Frequency Band
Ku
Transport Package
Airbox Packing
Specification
Radar main engine: 17.25kg,
Trademark
OEM
Origin
China
HS Code
8526109090
Production Capacity
1000

Product Description


Our company is positioned as a national high-tech enterprise engaged in the development and industrial application of short-range air defense system monitoring and early warning radar, electronic countermeasures technology. Our main products include low altitude target detection radar, bird detection radar, individual reconnaissance radar, two-dimensional three coordinate four sided array radar, electromagnetic interference, navigation deception and other standardized products. They are mainly used for low altitude safety defense of important targets such as troops, border defense, airports, nuclear power plants, and large conferences. Among them, the technology of medium and low altitude target detection radar has reached the leading level in China.
1. Low false alarm rate:
Multiple core technologies
Coordinated reduction radar
Detecting false alarm rate
2. High precision:
Direction and elevation
Accuracy of 0.3 °
Distance accuracy of 7m
3. Reliability:
Work all day, all weather, all terrain.
4. Fast and efficient:
Deployment time ≤ 10 minutes, retraction time ≤ 10 minutes
5. Modularization
Easy maintenance and repair, improving the flexibility and systematicity of the product
6. Intelligence:
Can be unattended, automatic detection, automatic report, to ensure real-time and effective lock intrusion
goal
7. High refresh rate:
Search data rate of 2s, tracking data rate of 10Hz
8. Gaze function:
Perform subsequent gaze tracking on the target
9. It can simultaneously detect fast, slow and high maneuvering targets 0.5-300 m/s
The company's products have passed environmental tests such as high and low temperature operation, high and low temperature storage, wind resistance, rain resistance, IP66, sand and dust, humidity, solar radiation, vibration, and impact.
Serial number Parameter name L5km
1 Operating frequency band Ku
2 system One-dimensional active phased array
3 Is it three coordinate radar Yes
4 Beam scanning mode Pitch electronic scanning
Azimuth mechanical scanning
5 Average power of whole machine < 250W
6 Detection power
( @RCS = 0.01m2 )
≥ 5km(DJI Phantom 4,RCS=0.01m2)
People: 3km
Car: 5km
7 Distance blind zone ≤ 150m
9 Azimuth range 360°
10 Pitch range 30°
15 weight Radar main engine: 17.25kg,
Turntable: 8.7kg,
Total: 25.95kg

Actual combat case:
