Long Range 7.7-8.5GHz Linear Amplifier Signal Booster Drone Detector Interference Signal Blocker Anti Drone Jammer RF Power Amplifier Module for Jamming System

Product Description

DESCRIPTION
This class A LDMOS module is designed for commercial applications.
It is capable of supporting any signal type and modulation format,
The latest device technologies and design methods are employed
to offer high power density, efficiency, and linearity in a small,
lightweight package.
FEATURES
Over / Under / Reverse Voltage Protection
High Speed On/Off Control
Over-Temperature Protection
Over-current protection
Optional Heatsink

Number	Item	Value	Remark
1	Frequency Range	7700-8500MHz
2	Liner Power	42dBm
3	Peak Power	49dBm	typical
4	Gain	40dB	typical
5	Gain Flatness	±1.25dB
6	IMD3	≤-25dBc	39dBm per tone
7	IMD3	≤-32dBc	35dBm per tone
8	VDC Voltage	+28V
9	Spurious	≤60dBc
10	2rd /Third Harmonic	≤20dBc
11	Turn on (0~90%)	≤10us

Q1.Can l obtain samples?
If the value of a single product is below 300 USD, samples can be provided depending on the situation.
Q2.Can l use my own logo or design on the product?
Yes, we provide OEM/ODM services; Your logo and design can be made on the product.
Q3. Do you have a factory?
Yes, we have a factory in Chengdu. Welcome to visit our company and factory. We are a professional manufacturer that provides OEM/ODM services to our customers.
Q4. What is the production capacity of your factory?
Our production capacity varies depending on the complexity of the product, ranging from 500 to 3000 units.
Q5.When will the shipment be made?
Inventory products will be inspected and shipped within 5 days, while non inventory products will be produced and shipped within 30 days
