Durable Screw for Injection Molding Machines Stainless Steel for ABC PP PE TPU Tpz PE PS PA66 PPS LCP PA6t PA9t PA4t PA9t PA46 PA6t

Durable Screw for Injection Molding Machines Stainless Steel for ABC PP PE TPU Tpz PE PS PA66 PPS LCP PA6t PA9t PA4t PA9t PA46 PA6t

US$550.00-1,300.00 1 Piece (MOQ)

Basic Info.

Model NO.
FC-S400/FC-S500/FC-S600/FC-S700/FC-S800
Standard
ISO9001:2006
Technics
Casting
Feature
Recycle
Material
Steel
Thickness of Bimetallic
1.5~3.0mm Depending on Different Alloy Coating
Hardness for Bimetallic
HRC50~70 Depending on Different Alloys
Surface Treatment
Bimetallic, Nitriding, Through-Hardened, Chrome-Pl
Transport Package
Wooden Box
Specification
900MM*25MM*25MM
Trademark
FACHANG
Origin
China
HS Code
7308900000
Production Capacity
8000 Pieces/Year

Packaging & Delivery

Package Size
180.00cm * 30.00cm * 40.00cm
Package Gross Weight
100.000kg

Product Description


Our different kinds of Screw Barrel sets suit for Brands of:
ENGEL,Krauss Maffei, ARBURG, Sumitomo DEMAG, JSW, HUSKY,NISSEI,HAITIAN, FANUC, YIZUMI,WELLTEC,TOYO, etc.
Cutomzied Screws and Barrels are available.
One Screw Barrel set including:
Srew, Barrel, Screw tip, Sleeve, Ring, Srcrew nozzle, Flange.
You just need let us know:
what is the brand and model of your machine?
what's the tons of your machine tons?
what plastic materials do you use?
how much GF do you add in the plastic materials?
------Then we can quote to you ASAP.
Our Production time: 20 to 30 canlendar days;

Screw Selection Guide
Model Product Name Technology Hardness Plastic Range Scope of application Wear-Resistant Corrossion-Resistant
FC-S300 Nitriding Steel Nitridation HV960 degree above No fiber added ABC/PP/PE/TPU/TPZ/PE/PS ★★ ★★
FC-S400 Double Alloys Bottom Grinding 58-60 Glass Fiber 30% or less PC/PPS/POM/PA/PBT ★★★ ★★
FC-S500 All Hard Alloys Bottom Grinding 60-62 GF 30% to 40% or less PA/LCP/PPS/PEEK/PEI bakelite,high viscosity, poor fluidity, PC white, PC transparent. ★★★★ ★★★
FC-S600 All Hard Powder Alloys Bottom Grinding 62-63 GF 30% to 50% or less PA/PA6/PPS/LCP ★★★★★ ★★★★
FC-S700 Ceramic Powder Alloys Spray 65-68 GF 50% or less V0 fireproof material, Dupont HTN, Flame retardant. ★★★★★ ★★★★★
FC-S800 Halogen Free Ceramics Spray 68-75 GF adding 50% + Halogen-free PA6T/PA9T/DSM PV4T/PA46/PA6T/ PA9T/PA10T and other highly corrosive halogen-free fiber adding plastics with 30%. ★★★★★★ ★★★★★★
