Precision Metering and Mixing Solutions for Industrial Slurry Processes
| US$100,000.00-10,000,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
KR-ZXAUTO
Application
Liquid, Liquid with Suspended Solids, Powder, Viscous Fluid
Application Area
Agricultural Chemicals, Chemical, Daily Chemical, Engineering & Construction, Food, Metallurgy&Mineral, Pharmaceutical
Certification
CE, ISO
Condition
New
Cooling Method
Water Cooling
Heating Method
Hot Water Heating
Main Material
Stainless Steel
Mixing Drum Shape
Circular Groove
Stirring Type
Spiral
Warranty
1 year
Working
Convection Mixer
Adaptive Process
Vacuum Conveying, Positive Pressure Conveying
Capacity
Positive 300L , Negtive 300L
Whole Line Power
Posive 240kw, Negtive 120kw
Power Supply
50Hz AC 380V Three-Phase Five Wire System
Grounding Resistance
Less Than 4 Ohm
Compressed Air
0.4-0.7MPa 15 M3/Min
Vacuum
Less Than -98kpa Flow Rate Greater Than 15m3/H
Cold Water
Less Than 0.3MPa, Pipe DN50
Usage Area
Indoor
Processing Material Samples
Iron Lithium,Graphite, Conductive Agent,
Usage
Convey Various Material to The Mixer
Powder Density
Less Than 2.5 Moisture Content Less Than 1000ppm
Material Type
PVDF,Cnt, Cme,Diw, Sp,NMP
Container Cleaning
Nitrogen Pulse Pressure Cleaning
Feeding Method
Manual Weighing Vacuum Conveying
Transport Package
Wood Pallet
Trademark
Career
Origin
China
Production Capacity
15000/Year
Product Description
Product Description| Equipment Name | Slurry automation system |
| Applicable process | Vacuum conveying, positive pressure conveying |
| Capacity | Equip equipment according to customer requirements |
| Machine power | According to the equipped equipment |
| Pilot run | Water or actual material |
| Processing material samples | Lithium iron, ternary, PVDF, SP, CMC, graphite, conductive agent |
| Usage | Transport various materials to the mixer |
| Processing powder density | ≤2.5 water content <1000ppm |
| Equipment equipped | Positive and negative electrode main powder feeding system |
| Positive and negative electrode feeding system | |
| Positive and negative electrode filling system | |
| Positive and negative electrode slurry conveying system | |
| Integrated system | |
| Vacuum system | |
| Main equipment details | High viscosity mixer |
| Main powder and auxiliary powder sending tank | |
| Small bag dust-free feeding station | |
| Glue making tank | |
| Glue storage tank | |
| Transfer tank | |
| Measuring tank | |
| Control system | |
| Sand mill | |
| Electrical instruments | Power wiring |
| Sensor | |
| Testing instruments |
Company Profile
Our esteemed KR Company, established in 2006 with its headquarters nestled in the dynamic heart of Dongguan, Guangdong Province, China, is a proud national High-tech enterprise. We specialize in the cutting-edge integration of research, development, production, sales, and service of intelligent devices. Our expertise revolves around core technologies including mixing, drying, grinding, dispersion, and sophisticated conveying systems. Our diverse product range encompasses intelligent power mixers, innovative vacuum dryers (systems), advanced sand mills, high-speed dispersers, and state-of-the-art automated homogenization conveying systems for powder, liquid, and slurry. We also offer comprehensive MES systems and logistic conveying solutions tailored for the lithium-ion soft engineering sector. KR Company excels in delivering a seamless, one-stop automation solution for material processing. Our services span unpacking, feeding, material storage, pneumatic conveying, precise batching, continuous metering, and beyond-right through to mixing, drying, pulping, dispersion, grinding, filtration, dust removal, and finished product packaging, all underpinned by intelligent control systems. Our products find versatile applications across a spectrum of industries such as new energy, chemicals, fine chemicals, daily chemical products, food, medicine, ceramics, coatings, and adhesives. We pride ourselves on our ability to tailor solutions to meet the unique customization needs of diverse customers, ensuring optimal equipment functionality and satisfaction.
