Metal Coil Automatic Stamping Press Servo Feeder Cut to Length Line Shearing Machine

Metal Coil Automatic Stamping Press Servo Feeder Cut to Length Line Shearing Machine

US$6,000.00-32,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
YT-CL
Drive Mode
CNC
Warranty
1 Year
Easy to Operate
Parameters Can Be Set up in PLC Touch Screen
Equipped Machine
Stamp Press, Roll Forming Machine, Shear Machine
Thickness Range
1.5-8.0mm
Application Material
Ss, SPHC, SPCC, Gi and So on
Industry
Automotive Parts, Electronics,Home Appliance
Feeding Length
0-9999mm
Feeding Precision
0.02mm
Coil Outer Diameter
1400mm
Coil Inner Diameter
450-530mm
Transport Package
Water-Proof Film
Specification
Machinery
Trademark
YITUO
Origin
Qingdao
HS Code
8462211000
Production Capacity
30 Sets Per Month

Packaging & Delivery

Package Size
480.00cm * 160.00cm * 270.00cm
Package Gross Weight
3000.000kg

Product Description

Product Description
Features of Uncoiled, Straighter and Feeder 3 in 1
1. Suitable all kinds of metal sheet straightening and feeding
2.Suitable for metal parts,electron,electrical appliance, toy and auto parts continuous pressing production,straightening and feeding.
3. Servo motor of this machine,electrical box and ome other parts are from Japan, with less malfunction and long using time.
4. Chrome plate,high precision,more durable.
5. Input feeding length, easy operation, safe and high stability.
Straightening capacity diagram
1.This diagram is suitable for condition,which material stretch intensity is 40kgf/ mm.
2. Straightening capacity may be change because of different actual condition.
3. About coil outer diameter,material widthand deciliter standard load weight,pleaserefer to deciliter attachment diagram ofthis catalogue.
4. About particular specification manufacturing, please contact us.

Specification
Model NCMF-300 NCMF-400 NCMF-500 NCMF-600
Ltem
Material thickness 0.4-2.5(Straighteningrollerl49x5up/5down)
Material width mm 300 400 500 600
Coil Inner diameter mm ф450~Ф530 ф450~Ф530 ф450~Ф530 ф450~Ф530
Coilouter diameter mm Ф1400 Ф1400 Ф1400 Ф1400
Coil weight kg 3000 3000 5000 5000
Decoiler power HP 2.2 2.2 3.7 3.7
Straightening power kw 2 2 3.5 3.5
Expansion style Hydraulic expansion Hydraulic expansion Hydraulic expansion Hydraulic expansion
Size m 4.5x1.5x2.3 4.5x1.7x2.3 4.5x1.9x2.3 4.5x2.0x2.3
Weight kg ~2200 ~2400 ~2800 ~3000

Model NCGK-500 NCGK-800 NCGK-1000 NCGK-1300
Ltem
Material thickness 1.5-8.0(Straighteningrollerl84x5up/5down)
Material width mm 500 800 1000 1300
Coil Inner diameter mm ф450~Ф530 ф450~Ф530 ф450~Ф530 ф450~Ф530
Coilouter diameter mm Ф1400 Ф1400 Ф1400 Ф1400
Coil weight kg 5000 5000 7000 7000
Decoiler power HP 2.2 2.2 3.7 3.7
Straightening power kw 5.5 5.5 7.5 11
Expansion style Hydraulic expansion Hydraulic expansion Hydraulic expansion Hydraulic expansion

Item Model NCBF-400 NCBF-500 NCBF-600 NCBF-700 NCBF-800 NCBF-1000
Material thickness 0.5-6.0(Straighteningrollerl68x4up/3down)
Material width mm 400 500 600 700 800 1000
Coil Inner diameter mm ф450~Ф530 ф450~Ф530 ф450~Ф530 ф450~Ф530 ф450~Ф530 ф450~Ф530
Coilouter diameter mm Ф1500 Ф1500 Ф1500 Ф1500 Ф1500 Ф1500
Coil weight kg 2000 3000 5000 5000 5000 5000
Decoiler power HP 2.2 2.2 3.7 3.7 5.5 5.5
Straightening power kw 4.4 4.4 5.5 5.5 5.5 7.5
Expansion style Hydraulic expansion Hydraulic expansion Hydraulic expansion Hydraulic expansion Hydraulic expansion Hydraulic expansion
Size m 4.5x1.9x1.8 4.5x2.0x1.8 4.5x2.1x1.8 4.5x2.3x1.8 4.5x2.5x1.8 4.5x2.8x1.8
Weight kg ~3200 ~3900 ~4800 ~5100 ~5600 ~6200
