Black H05VV-F 318y/3182y / 3183y / 3184y / 3185y Towline Electrical Flexibles Appliance PVC Cable

Product Description

H05VV-F Cable PVC Control Cable

Conductor:	Class 5 Flexible Stranded Copper
Insulation:	PVC
Outer Sheath:	PVC
Nominal Voltage U0/U :	300/500 V
Test Voltage:	2500 V
Minimal Bending Radius:	Fixed installation:6D (D = external cable diameter) Moved installation8D
Temperature range:	Flexible -5°C to +70°CFixed -40°C to +70°C
Application:	Flexible cable for medium mechanical stresses. Permitted frequent bending and twisting. Specially suitable for application in household, kitchens and offices in dry and damp conditions, for inst. washing-machines, dryers, refrigerators etc., as long as the cable is adapted to essential specifications of the device. Also suitable for cookers, i.e. hot devices, on condition that it does not get in direct contact with hot parts of the device and is not exposed to heat irradiation. Suitable for fixed installation in furniture, partition walls, decorative linings and cavities in prefabricated construction elements. Not suitable for permanent outdoor use (only temporary) or application for industrial or agricultural machines (except for sewing machines and similar)

BV,BLV,BVR,BVV,BLVV,BVVB,BLVVB,RV,RVB,RVS,RVV

Code Designation by GB	Rated Voltage	Name	Application	Rated Temperature
BV	300/500V	Copper conductor PVC insulated rigid cable (electrical wire)	Fixed laid indoors Instrument etc.	0°C to +70°C
BV	450/750V
BLV	450/750V	Aluminum conductor PVC insulated rigid cable (electrical wire)
BVR	450/750V	Copper conductor PVC insulated semi-flexible cable (electrical wire)	Be for laying permanent place where flexible required.	0°C to +70°C
BVV	300/500V	Copper conductor PVC insulated PVC sheathed round rigid cable (electrical wire)	Fixed laid, fit for the places with high mechanical protection and moisture place, can be laid in the air or underground.	0°C to +70°C
BLVV	300/500V	Aluminum conductor PVC insulated PVC sheathed round cable (electrical wire)
BVVB	300/500V	Copper conductor PVC insulated PVC sheathed flat cable (electrical wire)
BLVVB	300/500V	Aluminum conductor PVC insulated PVC sheathed flat cable (electrical wire)
RV	450/750V	Copper conductor PVC insulated flexible connector cable (electrical wire)	Mainly used at middle and light style moving electronics, home appliances, power and lighting and the places where flexible required	0°C to +70°C
RV	300/500V
RVB	300/300V	Copper conductor PVC insulated flat flexible connector cable (electrical wire)
RVS	300/300V	Copper conductor PVC insulated flexible twisting connector cable (electrical wire)
RVV	300/300V	Copper conductor PVC insulated PVC sheathed round flexible connector cable (electrical wire)
RVV	300/500V

Wuxi Reps Power Technology Co., Ltd. is located in C Area, Guanlin Town, Yixing City, Jiangsu Province. Enterprise development environment is superior, convenient transportation conditions, is a focus on special cable research and development, design, manufacturing and sales of a full range of science and technology service enterprises.
Our company has all kinds of professional production and technical personnel to provide technical support, at the same time has advanced professional production line and a complete set of testing equipment, perfect testing system and strict process testing to ensure the stability of product quality.
The company's main flexible cable, drag chain cable, tensile wear-resistant coil cable, grab cable. Garbage cable, scraper cable, gantry cable, coil cable, high flexibility cable, encoder cable, robot cable, robot arm cable, palletizer cable, tower cable, crane cable, driving cable, crane cable, Spreader cable, container crane cable, cold resistant cable and all kinds of flat cable, polyurethane cable, etc. Cover fixed installation, mobile installation of data communication, power transmission, all kinds of wire and cable products used in extreme environment.
It involves railways, highways, data transmission, oil and gas plants and petrochemical industries, environmental power, mining and tunnels, ports and ships, drum winding and communication applications.
"Cable Customization" is a special service close to the user of the Reps brand. With our years of experience, we can analyze the challenges faced by customers and bring together our expertise and cutting-edge technology, research and design solutions for supporting cable, and carry out technical services.
Q1: How can Iplace order?
A: You can contact us by email about your order details, or place order online
Q2: Does your company provide OEM&ODM services?
A: Of course, we can produce cables by your samples or technical drawings
Q3: Doed your company test all your goods before delivery?
A. Yes. we have 100% test before delivery
Q4: Are you a cable and wire manufacturer?
A: Yes, our company is an integrated set of industry and trade company.
Q5: Can you offer free samples?
A: Sure, the price is negotiable. We will definitely give a discount based on your annual order.
Q6: How long is your delivery time?
A: Of course, according to your order quantity, we'd like to provide free sample.
Q7: What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. Trade terms of EXW, FOB, CFR, CIF,are available.
