Saw Blade Sharpening Machine Sg-450
| US$1,800.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
SG-450
Condition
New
Warranty
12 Months
Sharpen Tool
Grinding Wheel
Sharpen Grinding Wheel Speed
4200rpm
Weight
160kg
Sharpening Type
Semi Automatic
Voltage
380V/220V/415V/230V/440V
Sharpen Saw Blade Outer Diameter
50mm-550mm
Sharpening Material
Circular Saw Blade
Sharpen Grinding Wheel Diameter
75mm-150mm
Sharpen Saw Blade Thickness
8mm
Transport Package
Packaging Details
Specification
800mm x 800mm x 1410mm
Trademark
Baorui
Origin
Jiangsu, China (Mainland)
Product Description
SG-450 Saw Blade Sharpening MachineTechnological data
| Item | Name | Data |
| 1 | Saw blade outer diameter | Φ50mm-Φ550mm |
| 2 | the teeth distance | 25mm |
| 3 | teeth depth | 8mm |
| 4 | cutting degree | minus 5°- 30° |
| 5 | feeding speed | 45-180 teeth/ minute |
| 6 | saw blade thickness | 8mm |
| 7 | grinding wheel diameter | Φ75mm-Φ150mm |
| 8 | grinding wheel speed | 4200RPM |
| 9 | the motor power | 1/2HP |
| 10 | the grinding wheel power | 3/4HP |
| 11 | Micro section adjusting angle | ±20° |
| 12 | Rotary corner | 30° left, 45°right |
| 13 | machine size | 800mm x 800mm x 1410mm |
| 14 | weight | 130kgs |
| 15 | Warranty time | 12 months |
Product show
