Dongguan Glc-1490 130W CNC Laser Engraving for Advertising Industry
| US$3,500.00-5,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
GLC-1490
Technical Class
Continuous Wave Laser
Automatic Grade
Automatic
Applicable Material
Nonmetal
Type
Flat-Plate
Laser Classification
CO2 Laser
Engraving Method
Vector Engraving
Model No
Glc-1490
Laser Source
Reci, Sp,Efr, Yongli
Warranty
One Year for Whole Machine, Except for Consumable
Other Parts Included
Exhaust Fan, Water Chiller, Air Pump
OEM Services
Supported
Package Dimension
2100*1600*1270mm
Export Markets
Global
Motor
Stepper Motor
Laser Type
CO2 Glass Laser Tube
Product Name
Laser Cutting Machine
Transport Package
Plywood Case
Specification
CE SGS ISO FDA
Trademark
Glorystar
Origin
Dongguan, China
HS Code
84561090
Production Capacity
3500 Sets / Year
Product Description
Dongguan Glc-1490 130W CNC Laser Engraving for Advertising IndustryProduct features
CO2 Laser cutting/engraving machines series are very popular in the market around the world. They has the high speed, high cutting accuracy and high stability. The quality and price ratio is very high.
This series laser cutting/engraving machines imported origionaly division stepping motor and driver from USA. Origional straight-line-guiding-track from Japan. High speed USB 2.0 port, LCD and silicon panel, water-cooling system, domestic-made glass CO2 laser tube, sealed
Laser beam by use of the imported Lens and mirros, ensure high cutting speed and long life time of laser tube.
Accessories
Applications
Engraving/cutting of fabric and leather in garment, embroidery, toy, handbag, glove precisioncutting of decoration board and non-metal board, like Acrylic and medium-density board in ads, upholstery, electrical appliance and plastic industry, Cardboard box industry, rubber printing plate engraving. Ultra-thick material surface carving.
Materials
Wood, paper, leather, choth, organicglass, resin, acrylic, wollens, plastic, rubber, ceramic tille. Crystal bowlder bamoo and other non-metal materia
Sample Show
Technical Data
| Model | GLC-6040/9060/1080/1290/1490/1610 | |||
| Laser Type | CO2 laser | |||
| Laser Power | 60W/80W/100W/130W | |||
| Engraving Speed | 0-64m/m | |||
| Cutting Speed | 0-36m/m | |||
| Repeat Accuracy | ±0.05mm | |||
| Moving System | CNC control system | |||
| Cooling Mode | Water-cooling and protection system | |||
| Overall Power Consumption | ≤1250W | |||
| Working Voltage | 220±10% 50Hz(60Hz) | |||
| Operating Temperature | 0~45ºC | |||
| Operating Humidity | 5%-95% | |||
| Controlling Software | Glorystar laser software | |||
| Graphic Supported Format | PLT,AI,JPG,PNG,TIF,PCX,TAG, MP,IOO,GIF, | |||
| Model | Working Area: | G.W. | Package Dimension: | |
| GLC-6040 | 600mm*400mm | 290KG | 1620mm*970mm*1270mm | |
| GLC-9060 | 900mm*600mm | 320KG | 1900mm*1250mm*1270mm | |
| GLC-1080 | 1000mm*800mm | 440KG | 1940mm*1500mm*1270mm | |
| GLC-1290 | 1200mm*900mm | 520KG | 2040mm*1600mm*1270mm | |
| GLC-1490 | 1400mm*900mm | 600KG | 2100mm*1600mm*1270mm | |
| GLC-1610 | 1600mm*1000mm | 660KG | 2280mm*1690mm*1270mm | |
