Factory Manufactured 6 Blades S14h Series Axial Fan for Power Generation Equipment

Product Description

Product Description
S1H/S13H/S14H/S16H
The fan diameter ranges from 141 to 745mm, and the blade twist angle can be adjusted from 20°to 50°to meet the different application requirement of the customer. The root is locked in the fan hub by a plastic fixing pin, which ensures that the blade will not be displaced after installation and the twist angle remains unchanged.
Advantages:
/ Higher efficiency
/ Less power consumption
/ Less noise/ Light weight and strength
/ Preservative
/ Optimized design according to customer requirements
Detailed Photos
We offer a wide range of bushings to meet the needs of a wide range of fan connections. For fans driven by hydraulic motors, the coupling shaft (conical or cylindrical) is generally small in size. We can provide forging and casting. Heat treated bushing.
The bushing diameter, the key and the optional
countersunk screw hole can be supplied according to the customer's design requirements. We can also provide the bushing directly processed from the bar according to the customer's requirements.

FAQ:
Q: Are almost all fans replaceable?
A: Yes
Q: Can they be fitted?
A: We can machine the connection holes and bushings, so they can definitely be fitted.
Q: Is it safe to use?
A: We will balance and match the angle to the power speed.
Q: Is it possible to replace only the blades?
A: No problem, the design is exactly the same Product Parameters
Material of blade

Symbol	Material	Temperature range	Characteristic	Application
PA	Nylon6,Black	-40ºC-110ºC	Anti-aging	Standard load
PAG	Nylon6,Black and white	-40ºC-110ºC	Anti-aging	Heavy load
PAGST	Nylon6,Black	-40ºC-110ºC	Shock and impact	Strong vilbration occasion
PACAS	Nylon6,Blue-gray	-30ºC-100ºC	Conductivity Fire resistance	Explosive danger
ALU	Die-cast aluminum alloy	-40ºC-150ºC	Large temperature range	High temperature

Blade Diameter rang

S1H/S13H/S14H/S16H Blade number	Fan diameter mm (Minimum-Maximum)
	S1H/S13H/S14H/S16H
5	357 - 1028
7	394 - 1065
8	474 - 1145
9	408 - 1079
12	488 - 1159
16	583 - 1254

Application

Packaging & Shipping
We can deliver by air and sea
One unit we reinforce with a cardboard box
For multiple units we will use fumigation-free wooden boxes
Company Profile
UTEK-DELE Technology Changzhou Co., Ltd is committed to provide tailor-made service to customers with various requirements, mainly including axial fan.
General items: Sales of fans and fans, sales of high-performance fiber and composite materials; Sales of metal matrix composites and ceramic matrix composites, sales of civil aviation materials, sales of new ceramic materials, sales of special ceramic products, sales of glass fiber reinforced plastic products, sales of synthetic materials, sales of graphite and carbon products, sales of glass fiber and products, sales of building waterproof coiled materials, sales of chemical products (excluding licensed chemical products), sales of special chemical products (excluding hazardous chemicals), Sales of instruments and meters, repair of instruments and meters, technology promotion and application services (in addition to projects that need to be approved according to law, independent business activities shall be carried out according to law with the business license)
Factory Show
UTEK-DELE has its own processing capabilities and can customise products for customers, as well as R&D production capabilities
Certifications
Partners
UTEK-DELE ADVANTAGE 1.Same quality as wingfan and multiwing
2.Software to design the model
3.Full sets of blade and hub
4.Fast delivery
Give us a chance, and we' ll return you with satisfaction.
