Sticker Label Die Cutting Machine for Sticker Labels Auto Flat Die Cutting Machine with Servo Motor
| US$16,000.00-20,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
KTLP-DF 320 KTLP-DF 420
Imprinting Type
Label Flat Die Cutting Machine
Computerized
Computerized
Automatic Grade
Automatic
Application
Paper Packaging Materials, Stickers Products, Heat Insulation Material, Insulating Materials, Dust-proof Material, EMI Shielding Materials, Earthquake Products, Adhesive Label Flat Die Cutting Machine
Die-Cutting Adhesive Labels
Yes
Die-Cutting Hologram Labels
Yes
Speed
20-220 Times/Min
Hole Punching Station
Optional
Hot Stamp Function
Optional
Laminating Film Function
Optional
Keyword
Sticker Label Die Cutting Machine
Keyword 1
Auto Flat Die Cutting Machine
Keyword 2
Flat Die Cutting Machine
Keyword 3
Die Cutting Machine with Servo Motor
Keyword 4
Die Cutting Machine for Sticker Labels
Keyword 5
Die Cut Label Machine
Keyword 6
Flat Bed Label Die Cutting Machine
Keyword 7
Die Cut Label Machine
Keyword 8
Automatic Flat Die-Cutting Machine
Transport Package
Wood
Specification
2950 x 1350 x 1400mm
Trademark
KETE
Origin
Wenzhou, Zhejiang Province, China
Production Capacity
20 Sets/ Month
Product Description
This Label Die Cutting Machine Use a Flat Die Cutting System with Servo Motor Control, It Is Suitable for Die Cutting All Kinds Of Adhesive Labels And
Hologram Labels. It Is the Converting Machine for The Flexo Printing Machine.
* Optional: Hole Punching Station * Optional: Hot Stamp Function (Servo Motor Drive) * Optional: Laminating Film Function
| Model: | KTLP-DF 320 | KTLP-DF 420 |
| Max. Unwind Diameter | 500mm | 500mm |
| Max. Raw Material Width | 320mm | 420mm |
| Max. Die Cutting Width | 300mm | 400mm |
| Max. Die Cutting Length | 300mm | 400mm |
| Die Cutting Speed | 20-220 Times/min | 20-210 Times/min |
| Positioning Precision | ±0.15mm | ±0.15mm |
| Machine Power | 3.5kw | 4.5kw |
| Machine Weight | about1700kg | about2300kg |
| Machine Size (LWH) | 2600 x 990 x 1400mm | 2950 x 1350 x 1400mm |
| Power Support | 3 Phase 220/380/440V 50/60HZ | |
