Dock Leveler: Speed Safety Valve & Anti-Fall Protection

Product Description

Hydraulic Dock Leveler(Connects Truck And Platform For Easy Loading And Unloading)

Hydraulic Dock Leveler
The dock leveler can effectively compensate for the height diference between the truckand the building platform. When the truck stops near the platform and stabilizes, themain panel and the slab are lifted up to the truck compartment board by starting theelectro-hydraulic system. The handling vehicle can directly enter the compartment forloading and unloading operations, safe and efficient. In the structural design andmaterial selection process, the safety of the user is always the first priority. The actuacarrying capacity of the hydraulic dock leveler produced is greater than the load-bear-ing regulations in the relevant international standards

Product Details

Part Name	Configuration
Platform size	(W*L*H) 2000*2000*500(mm)
Foundation size	(W*L*H) 2030*2000*510(mm)
Load	Dynamic load 6800kg/ static load 13600kg
Platform color	Grey (customizable)
Countertop panel	Thickness 8mm, antiskid pattern steel plateof Baosteel
Lip	Thickness 16mm, whole sheet of antiskidpattern steel plate
Frame under countertop	10 pieces of C steel
Hinge	Thickness 10mm
Connecting shaft	Diameter 28mm
Hydraulic system	Dedicated hydraulic unit, motor power 0.75kW 380V50HZ
Control system	Control system: CPU integrated control system with screen displaying running status, running times, fault code and interlock, linkage expansion function; One-Key operation, power shut off
Hydraulic cylinder	Adopt design of main cylinder (lift of main panel) and auxiliary cylinder (flip of lap plate); concise arrangement of hydraulic pipelines,Adopt Japanese NOK seals
Hydraulic tubing	Imported Goodyear brand, pressurevalue 220 bar
Foot guard	One piece thickness 1.5mm
Settling time	30seconds (any position to corresponding maximum limit range)
Adjustable range	+350/-300mm
Operation temperature	+50°C~-25°C
Painting	Surface treated by pickling, derusting and sandblasting, and adopted automatic spraying anti-rust paint, primer and finish paint layer thickness 0.1mm
Hydraulic tank capacity	5L
Hydraulic oil pressure	120bar
Lip self-lock	With, standard configuration
Maintenance support bar	With, standard configuration
Safety hydraulic lock valve	With, standard confiquration
Adjustable speed hydraulic valve	With, standard confiquration
Bumper block	One pair,250*300*100mm
Electric cabinet	IP55
