Knee Type Unisersal Milling Machine, with Auto Feeding Worktable, Vertical Milling Head.
| US$3,500.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
X6330
Type
Worktable Milling Machine
Object
Hardware
Structure
Bed type
Milling Cutter Type
Cylindrical Milling Cutter
Milling Cutter Structure
Indexable Type
Controlling Mode
Artificial
Automatic Grade
Semiautomatic
Precision
Precision
Certification
GS, CE, ISO 9001
Condition
New
Specification
X6330
Origin
China
HS Code
84595900
Production Capacity
1000PCS/Year
Product Description
Knee type unisersal milling machine, with auto feeding worktable, vertical milling head.Feature:
1 .Taiwan original milling head, NSK P4 spindle bearing. 2.Work Table Surface and Guide ways Hardened by Supersonic Frequency Quenching (depth 2-4MM)
3.Work Table Made by HT200-250 High Strength Cast Iron
4. With the horizontal milling function
5.Plastic Guide Way Increase The Precision And Service Life
6.Three Axis can Fix (X/Y/Z) Automatically Feed .
7 .Taiwan original milling head, NSK P4 spindle bearing.
8. Dovetail Type , Rectangle Type ,Horizontal Type .Can Choose Main technical specifications:
| Model | Units | X6330(5HW) |
| Table size(mm) | mm | 1370X305 |
| Long travel(mm) | mm | 900 |
| Cross travel(mm) | mm | 400 |
| Vertical travel(mm) | mm | 420 |
| T-slot No. and size | 3x16 | |
| Ram travel(mm) | mm | 500 |
| Distance from spindle nose to table surface(mm) | mm | 0-500 |
| Spindle hole taper | mm | Standard:R8 Optional: ISO30/ISO40 |
| Spindle travel(mm) | mm | 127 |
| Spindle speed | Standard:16steps Shift grade: 50HZ:65-4500 60HZ:80-5440 horizontal 45-1350(12 step less) | |
| Optional : stepless Variable: 65-4500 | ||
| Auto quill feed | kg | Three steps: 0.04/0.08/0.15 mm/revolution |
| Telescopic stroke | mm | 470 |
| Spindle power | KW | V 2.2KW/3HP/ (Optional 5HP) H 2.2KW / 3HP |
| Head swivel | ° | 90 |
| Head tilting | ° | 45 |
| Dimension of package | mm | 1516x1550x2235 1680x1790x2235(include 2 sets) 1650x2285x2235(include 3sets) |
| G.W./N.W. (kg) | Kg | 1200/1550 |
