Power Electric 70kVA 70 kVA Ricardo Diesel Generator Electricity Generation Super Silent Price List

Product Description

Power Electric 70kVA 70 kva Ricardo Diesel Generator electricity generation Super Silent price list
ONEW diesel generators are strong-built, ideal for emergency back-up,job sites and industrial appplications.
Powered by reliable air/water cooled diesel generators sets, industrial grade, great fuel efficiency, less maintenance, long operating life.
Low oil shut-down provides added safety against engine damage.
8-10hours long run fuel tanktank with fuel gauge.
stainless steel parts with door lock and hinge fuel tank lock.
Strong frame/capony, durable and strong protection and security on the job.
Hour meter / maintenance resets - easily monitor run time and track maintenance intervals.
Optional ATS sockets for connecting with an external automatic transfer switch.

genset type	rated output	Engine (Kofo)	Alternator	control
	KW/KVA	model	model	Comap
GF2-111	56/70	R6105ZLDS	ON-56KW (100%COPPER)	Comap IL3AMF9
Genset SIZE	2700x1050x1470mm(4.42cbm)
Weight	1295kgs
Fuel comsuptions 100%Loading	24L/H
Base Fuel tank	8-10hours fuel tank
Engine Data sheet
Engine model	R6105ZLDS		% Steady speed adjusting rario at rated condition	≤5
Type	Water cooling,in line,four-stroke,wet liner and direct injection		Mpa Oil pressure	0.3-0.5
Number of cylinders	6		r/min Idling speed	≤650
Bore/Stroke mm	105-125		Mpa Oil pressure at idle speed	≥0.10
Displancement L	6.49		g/kW.h Oil consumption rate	1.63
Compression ratio	16:1		L Oil sump capacity	18
Aspiration	turbo & inter cooler		Starting method	Electric motor start
Rated output kW	100		Lubricating method	Pressure lubrication
Rated speed r/min	1500		Crankshaft rotating direction	Counter clockwise(face to output end)
g/kW.h Fuel consumption rate	≤231		Fring order	1-5-3-6-2-4
r/min No load Speed	≤1575		Net mass kg	620
Alternator data sheet
Brnad	China brand		Pressure regulating mode	AVR automatic pressure regulation
model	ON-56KW		bearing	Long life and no need maintencances
Prime power	56kw		Class of insulation	H grade
Exciation mode	Brushless self-excitation		protection	IP23
Power factor	0.8

ONEW has been focusing solely on diesel products since day one.Products includes AIR/WATER COOLED DIESEL ENGINES, GENERATORS sets and Spare Parts. ONEW Generators to power their homes, factory, contructions,resell, etc.
Click https://onew-power.en.made-in-china.com/ for further information.
Warranty
The products will be tested stricly one by one before delivery with testing video to customer.
Germany production processes and quality standards to guarantee the good quality.
Our warranty is 1 year or 1000 running hours whichever comes first.
But based on some special project,we can extended our warranty period.
Please help us to find out the problem, and we will offer free components for service.
All products will be well packaged and will not be damaged in transit.
FAQ 1.How to buy your product?
You can place an order directly through the start order of Made in china
or send email ,add whatsapp to talk
2.Do buyers need to contact the seller after placing an order?
No, we will contact you as soon as possible by made in china and prepare to ship.
3.How long does it take to receive the product after placing an order?
3-15 days from deposit, after your order, we will contact you and tell you the specific time.
4.how many MOQ?
MOQ is 1
5. Are you a manufacturer or trading company?
We have large factorys, R&D teams and foreign trade teams.
6.How spare parts supply of generator?
We can send u free spare parts during warranty by DHL
7.What kind of diesel use?
#0 diesel
8.How could I trust you?
Diesel Service & Supply stands behind the quality of all the used generators and industrial power equipment we sell. If you are not convinced by the pictures, videos, check-in reports, load tests, customer experiences and sales associates' knowledge about the generator you are interested in, then we invite you to come visit our expansive yard and shop facility to witness a load test and see the professional operation we have going on here.
ONLINE PAYMENT TRADE ASSURANCE AVAILABLE
If You Are Interesting In ONEW, Pls Contace Us Freely ,Welcome To Visit ONEW!!
