DIY Tube Flexible 360 Degree D18 LED Neon Rope LED Light RGBW

Product Description

360° D18 Neon Product advantage
PRODUCT FEATURES-Circular tube profile supports 360° circular luminous surface, uniform luminous area without dark area, suitable for space decorative lighting; -Free to cut any length can be rigid, flexible, plasticity, bending and pliable; -IP67 waterproof grade, can be used outdoors, the use of silica gel material, flame retardant, corrosion resistance and UV resistance; -50000 hours long life, 5 years warranty, UL and CE certification;-High transmittance high purity silica gel material, protection grade IP67; -Support multiple installation methods such as hanging and surface installation..advantage:
compared to D25 Neon,D25 colloid weighs 570g,while D18 only 295g, N.W for a meter is around 315g,Colloidal product decreased by 50%,price is around 11usd. .Smaller bending diameter,D25 Min. bending diameter is 200mm, D18 vertical bend can reach 150mm.
Cut as your mind360° Light-Emitting
SPECIFICATION

Dimension	Diameter 18mm
Color Rendering Index	Ra>90
Beam Angle	360°
Operating Ambient temperature Ta	-20-45° C [-4~113° F]
Lifespan	50,000H
Input Current/m	0.6~0.8A/M
Static Electricity	1000V (ESD)
Warranty	5years
Enery Grade	G

General Parameters
IES Data
Drawing
1,Use D18 tube,appearance white,Spray handle oil after the product process;
2,Produce size ∅18mm±0.25mm.3,The head end uses a flat cap with front wire outlet which has same size as strip;
4,Use waterproof quick wire connector for easy splicing;Cable entry method
Accessories color can be customized
Notice: 1. Luminous flux or CCT 2700K is 10% lower, or CCT 3000/3500K is 5% lower, for CCT 5000K/ 6500K is the same compared with 4000K. 2. Energy efficiency dass of regulation (EU)201 9/2020 is F(CRI80) for 4000K and G(CRI80) for CCT, it waries depending on CRI and CCT. 3. The transmission direction of data must be from PI to Po following the arrow printing on FPC for DMX/SPI version, and can't be made by reverse connection, otherwise the strip will be out of control or even domaged. INSTALLATIONThe LED neon Flex can be bendable and twistable any angle, like the following drawing; Accessory: Entry Cap, and End Cap, Mounting Clip.
You can be creative to determine the neon display effect.
Ceiling mounting
Hanging mounting
APPLICATION
Other specifications
