70HP Agricultural Farm Rubber Track Crawler Tractor with Rotary Tiller

70HP Agricultural Farm Rubber Track Crawler Tractor with Rotary Tiller

US$18,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
W702
Application Field
Agriculture
Farming Policy
Paddy Field Machinery
Power Source
Diesel
Arbor Configuration
Horizontal Axis
Color
Red
Warranty
2 Years
Engine
70HP
Weight
2680kg
Model
Rubber Tractor
Supply Ability
50000units/Year
HS Code
84378000
Production Capacity
10000units/Year

Product Description

50-100HP Farm Tractor,Rubber Tractor,Crawler Tractor



Product Description 1.Farm tractors engine form adopt renowned directly injection vertical water cooled 4-stroke(In line,EFI,water cooled,4-stroke) YTO/CHANGCHAI engine.
2.Agricultural equipment tractors Walking rubber track pitch section*number*width: 90*46*300(W602,60HP) 90*46*350(W502,50HP) 90*50*350(W702/802,70/80HP) 90*51*350(W702,70HP) 90*54*400(W802/902,80/90HP) 90*56*500(W902/1002,90/100HP)
3.China best selling tractors cltuch:single-plate, single-acting, wet friction clutch Type.
4.Our farm tractors Minimum ground clearance(mm):260,400,410,530,610.
5.Equipment farming tractors of gear box:F12+R12;F8+R8;2(machanical gear)+2*2(hydraulic stepless speed change);Main transmission(hydraulic stepless speed change+machanical gear)+2(secondary speed change).
6.PTO:φ38,8teeth φ38,6teeth,Speed:720/1000.Linkage:II Rear Mount 3-point Linkage. We can produce and customize all sorts of medium-sized tractor 50 HP - 100 HP farm crawler tractors, diesel type, electric type can be customized production, and the tractor with all series farm implements, such as ridging machine,rotary tiller,disc plough, flattener,ditching machine,windrower,harrow, loader, backhoe, trailer,mower,grass chopper,silage corn straw harvester,small excavators etc you want. But firstly, tell us your preferred horsepower tractor.

Product name
Rubber Tractor ,Crawler Tractor
Minimum ground clearance (mm)
400




Engine
Mode
YD4CZ70C1
Form
direct injection ,vertical,water cooled,four-stroke
Rated power(kW)
51.5
Fuel
diesel fuel
Rated speed r/min
2400
Starting method
electric start
Steering brake system
Steering System Type
planetary differential steering
Brake system type
wet friction type

Drive train
Clutch type
single - chip single - acting
Transmission type
8 eight forward speed+reverse gear
Transmission shift mode
gear shift



Walking system
Rack form
rigid frame type
Track Pitch section × number × width
90×51×350
The theoretical speed of each file(km/h)
go ahead 1.22;1.80;2.92; 3.84;5.50;8.08;13.13;17.25 Backward:0.97;1.43;2.32;3.04;4.36;6.41;10.42;13.68



Working device
Lifter type
semi-Split
Tillage depth control
force adjustment
PTO form
type1, non-independent
Power output shaft speed(r/min)
720/1000
PTO shaft spline and the outer diameter mm
8×38
