Original Factory Hydraulic Hose Press Machine Hidrulic Hose Press Machine P32 3kw Hydraulic Hose Pressing Machine for Sale

Original Factory Hydraulic Hose Press Machine Hidrulic Hose Press Machine P32 3kw Hydraulic Hose Pressing Machine for Sale

US$1,499.00
1-4 set
US$1,399.00
5-9 set
US$1,299.00
10+ set

Basic Info.

Model NO.
MJhyd 52T
Certification
ISO, SGS
Condition
New
Customized
Customized
Automatic Grade
Automatic
Structure
Horizontal
Crimp Hose ID Range
1/4-2" or 6-51mm up to 2" 4sp
Crimp Od Range
4-80mm
Max Opening
114mm
Motor Power
3kw/4kw/5.5kw or Customize
Voltage
220V / 380V or Customize
Open and Close
+/-30mm
Oil Pump
2.5L/5L/10L
Scale Accuracy
0.01mm
The Largest Crimp Force
560t
System Pressure
31.5MPa
Dies
10 Sets
Dies Number
15 19 23 26 31 36 41 47 55 63mm
Gross Weight
320kg
Packing Size
87*65*81cm
Spares
Lamp, Oil Seal
Transport Package
Wooden Box
Specification
87*65*81cm
Trademark
MJ hyd
Origin
China
HS Code
8479819000
Production Capacity
500 Sets/Month

Packaging & Delivery

Package Size
87.00cm * 68.00cm * 81.00cm
Package Gross Weight
330.000kg

Product Description

Quick change and rack 1/4-2" P32 hydraulic hose crimping machine Product Description
Crimping inner diameter range 1/8-2" 3-51mm 1-4 wire
Crimp outer diameter range 4-80mm
Motor power regular use 3KW,still have 4KW or customize power for choose
Voltage 220V single / 380V 3 phases or customize
Oil pump 2.5 220V/ 5L 380V or 10L for choose if necessary
Max opening 114mm
The max open tolerance ±30mm
Scale accuracy 0.01mm
Operate methods Automatic, button or foot pedal
Dies molds regular 10 sets ,could customize for more
Dies number 15mm 19mm 23mm 26mm (length 60mm)
31mm 36mm 41mm (length 70mm)
47mm 55mm 63mm (length 80mm)
Packing size L 870 * W 650 * H 810mm
Gross weight 320KG
Detailed Photos
Work on different hose
Factory product process
Payment methods We usually accept the payment via T/T(Telegraphic Transfer/bank transfer), Payment on line, Wetern Union payment and so on.
Usually 30% in advance and balance pyament before delivery. If you have any question,please contact me.
FAQ Q1 : Are you factory ?A1: Yes,we are factory,and our factory has over 18 years experice for product the machines;Q2: Do you have the machine in stock?A2: We usually keep the machine in stock, please kindly tell me which model you want,we will provide you more detail information.Q3: Could you customize the voltage ?A3: Yes,we can customize the voltage ,we have experience customize on 230V 240V 400V 415V and 110V, if you want customize the voltage,please contact me.Q4: How about the warranty?A4: Firstly our machines have 3 years warranty time,its long term warranty for this kind machine;Then we very confident that if you crimp the hose/fitting within its ability and operate right way,the machine would not workwrong;If your machine cann''t work,please contact us,we will help you fix it or send you some spares.Q5 : Could you customize dies molds?A5 : Yes,we are very experience on customize dies, suck like for air conditioning,brake hose and so on. We could customize thedies pattern or dies number regarding your requirement.Q6: Does the machine operate easily?A6: Yes, We complete testing each machine before send,no need anymore adjust,we package installation instructions and use tip foreach machine,we also could provide the operate video.Q7 :Can you produce product with my own brand?A7. Yes, it''s available except famous brand which are not allowed.Q8: Could you customize color for me?A8: Yes,we can customize the color regarding your requirement.
