2022 China Used Tire Rubber Crusher for Rubber Powder Line

Product Description

Product Description
Rubber Powder Production Line/Rubber Tire Crusher
Automatic Production Line Process
Waste Tires-→Single Hook Debeader-→Tire Cutter-→Whole Tire Shredder-→Rubber Crusher -→Oscillating Screen,
Conveyor Belt, Magnetic Plants-→Fiber Separator -→Fine Rubber Powder Pulverizer-→Rubber Powder
Semi-Automatic Production Line Process
Waste Tires-→Ring Cutter-→Press loop Machine-→Strips Cutter-→Blocks Cutter-→Rubber Crusher -→Oscillating Screen,
Conveyor Belt, Magnetic Plants-→Fiber Separator -→Fine Rubber Powder Pulverizer-→Rubber Powder
Rubber Crusher ( It will be chosen according to your need capacity)
1. This Rubber machine is used for crushing rubber and plastic. The roll made of alloy chilled cast iron is better
than those of common chilled cast iron.
2. The interior of the two rolls is empty and spray type. The temperature of roll surface is even.
3. To assure the safety, we install emergency pulling up equipment. Convenient range adjustment is set in
manually operation. The safety shut down in manual operation is set, with the function of automatic crawl back
swing the roll.
4. Convenient range adjustment is set in manually operation. The whole machine adopts channel-bottom head for
convenient carrying and maintance.
The Rubber Powder has more Applications, please refer to the below introduce:
5-10 mesh: runway, school playgrounds, garden paths, bowling alleys, sidewalks, composite rubber floor tiles,
anti-static floor tiles, artificial turf, playground, artificial turf soccer field the the kindergarten sports venues and
casino tennis and basketball courts.
10-20 mesh: rubber floor tiles, plastic runway, lawn quartz sand, cottonseed husk pellet, tennis courts, volleyball
courts, a golf course, aircraft pitch, basketball court and recreational field, EPDM safety mats, gym mats, all
kinds of The stadium floor mats.
30 mesh: plastic insulation material, waterproof material, shockproof, washers, roof and wall waterproofing
membrane, modified bitumen additives, reclaimed rubber, livestock, straw mats, fender, multifunctional mat,
stable mat.
40 mesh: reclaimed rubber waterproofing membrane, modified bitumen additives, carpet padding, sleepers,
rubber sheet, livestock grass mats, rubber water-stop gate waterstops, bearings, seal, buffer, brake brake linings
cover, drainage pipes, gloves, rubber bands, elastic band, roof signs, brick material top liner, sanitary pumps,
corner glue, wheel alignment, the pump pumping sand pads, fenders, multi-function pad, stables pad, resistance
burning material, sound insulation materials, rubber and rubber-soled, window sealing strip of rubber products
and agricultural Oaks (milk) Polystyrene.
60 mesh: sleepers, rubber sheet, waterproofing membrane, reclaimed rubber, tire inner cushion, car underbody sealed,
waterproof ring, rubber miscellaneous pieces the alternative native gum production of rubber products.
80 mesh: modified asphalt additives, reclaimed rubber, waterproof membrane, the size of the tire additives, sleepers,
deceleration road humps, sealing strips, buffer, styrofoam pearls pad, rubber products, rubber piston, brake gate bushing.
100 mesh: automotive bias tires auxiliary specialized packing of materials, footwear, sports equipment tires.
120 mesh: plastic pipe insulation material additives, automotive bias tires auxiliary materials, car refurbished outside pad,
dedicated shoe filler, chemical sealant various rubber seepage mixtures.
200 mesh: building material coatings, automobile tires, and alternative raw rubber production of various rubber products.

Technical parameter \ Type	XKP-400	XKP-450	XKP-560
Front roll diameter(mm)	400	450	560
Rear roll diameter(mm)	400(Groove roller)	450(Groove roller)	510(Groove roller)
Working length of rolls(mm)	600	650	800
Front roll surface speed(m/min)	17.32	23.2	25.56
Friction ratio	1: 1.38	1: 1.38	1: 1.
