All-in-One Pipe Cutting and Beveling Machine
| US$20,000.00-100,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
AUTO MPFS
Suitable for Material
CS/Ss/as
After-Sales Service Provided
Engineers Available to Service Machinery Overseas
Applicable Industries
Oil&Gas, Refinery Facilities, Offshore&Shipbuildin
Control Mode
PLC
Cutting Accuracy
1mm
Transport Package
Packed in Container
Specification
ISO9001: 2008
Trademark
NAEC
Origin
China
HS Code
85153190
Production Capacity
200 Sets/Year
Product Description
NAEC---- Lean Fabrication Service Operator for Energy Engineering Industry!Suitable for industries of: OIL AND GAS, REFINERY FACILITIES, OFFSHORE &SHIPBUILDING, POWER PLANT, ETC.
Reference: CCC, Larsen & Toubro, PEC, Rotary Engineering, Petrol Steel, JSL, Tamimi, AIM, CNPC, SINOPEC, CNOOC, CNCEC, etc.
3D Video of All-in-one Pipe Cutting and Beveling Machine
Features:
| 1 | One cut-off with two pipe end beveling |
| 2 | High speed pipe cutting & beveling |
| 3 | Suitable for small pipes |
| 4 | Max. Thickness: 20mm |
| 5 | Cutting efficiency: 100 times/8hrs |
| 6 | PLC control with automatic measuring function |
| 7 | Widely used for small bore C. S/S. S pipe spooling fabrication production lines. |
| 1 | Pipe Cutting& Beveling All-in-one Machine >Suitable for pipes not larger than 8",max.thickness:20mm >Cutting efficiency:100times/8hrs >PLC control with automatic measuring to guarantee the same processing cycle >Widely used for small bore C.S/S.S production lines | |
| 2 | High Speed Band-saw Cutting Machine >Three models available(16"type,24"type",48"type) >PLC system control;self-measuring function with precision:±0.5mm >Using hydraulic self-centering chuck >It only takes 6 minutes to cut a 24" pipe of 25mm thickness >Widely used for C.S/S.S production lines. | |
| 3 | High Speed CNC Pipe End Beveling Machine >Automatic self-centering chuck >Single V,double V,U type bevel >Can be matched with pipe end turning devic >High speed beveling:for example,it only takes 2.5minutes to get a 37.5 degree bevel for a S.S pipe end(diameter :610mm,thickness:25mm) >Several models available:16",24",32",48" | |
| 4 | Two / Multi- Axis CNC Flame/Plasma Cutting Machine >High efficient pipe cutting with automatic self-measuring function, pipe end beveling, intersection line profiling for both main and branch pipe. >Five/multi-axis cutting machine can profile more complicated outlines with various bevel type >Standard machine suitable for pipes nor larger than 24'' | |
| 5 | Multi-function Pipe Fitting-up Station >Suitable for flange,elbow,tee,reducer to pipe and special T-joint fitting-up. >Light-duty type(manual) and heavy-duty type(motorized) are available. >Different types available, 8" type, 24" type, 32" type, 48" type, 60" type | |
| 6 | Automatic Pipe Welding Station >With two welding heads >TIG/MIG/SAW are optional >PLC system control & WPS programmed >Max. efficiency fo reach welding head can be 400D.I/8hrs even use TIG/MIG technology. >Different types available, 8" type, 24" type, 32" type, 48" type, 60" type | |
| 7 | Conveyor Handling System >used for pipe convenient transporation during in pipe spool fabrication. >Its speed is adjustable between 2M to 20M/min. |
For the 3D Video of All-in-one pipe cutting and beveling machine, you can also see it from below link: http://youtu.be/YS6vCgrV7Lo
