SAE Standard Braid Hydraulic Hose 1sn 2sn

Product Description

Product Description
1. Tube: Oil-resistant synthetic rubber
2. Reinforcement: Two braid of high tensile steel wire
3. Cover: Oil and weather resistant synthetic rubber
4. Application:Be suitable for hydraulic application with increased resistance to abrasion for use with petroluem, water,etc.
5. Safety factor:4:16. Temperature Range:-40ºC to 100 ºC

Size		Inside		Outside	Working		Burst Pressure		Bend Radius	Length	Weight
		Ø mm		Ø mm	Pressure
Inch	mm	Min	Max	Max	Bar	Psi	Bar	Psi	mm	m	Kg/m
1/4	6.4	6.2	7.0	17.5	400	5800	1600	22840	100	50/100	0.42
5/16	7.9	7.7	8.5	19.1	360	5250	1400	20000	114	50/100	0.51
3/8	9.5	9.3	10.1	21.4	331	4800	1320	18840	127	50/100	0.6
1/2	12.7	12.3	13.5	24.6	276	4000	1100	15720	178	50/100	0.74
5/8	15.9	15.5	16.7	27.8	250	3630	1000	14280	200	50/100	0.86
3/4	19.0	18.6	19.8	31.8	215	3120	850	12280	240	50/100	1.04
1	25.4	25.0	26.4	39.7	165	2400	650	9420	300	50	1.42
1 1/4	31.8	31.4	33.0	50.8	125	1820	500	7140	419	50/100	2.23
1 1/2	38.1	37.7	39.3	57.2	90	1310	360	5140	500	50/100	2.74
2	50.8	50.4	52.0	69.8	80	1160	320	4560	630	50/100	3.5

More ProductsWe are manufacturing and marketing all kinds of hydraulic hose&fittings, we can also produce according to customer's drawings or samples.
Hydraulic Hose(Full range of DIN and SAE):
Wire braided: SAE R1/DIN EN 1SN, SAE R2/DIN EN 2SN, SAE R16, SAE R17
Wire spiral: SAE R9, R12, R13, DIN EN 4SP, DIN EN 4SH
Textile braided: SAE R3, SAE R6, SAE 5
PTFE Hose, SAE R7, SAE R8
Industrial Hose:
Air hose--WP 20 bar/300 PSI, BP 60 bar/ 900 PSI. 50-100M per roll.
Water hose--WP 20 bar/300 PSI, BP 60 bar/ 900 PSI. 50-100M per roll.
Suction hose--Water suction hose, water discharge hose, oil suction hose, oil discharge hose.
Sand blast hose--High abrasion resistant tube.
Welding hose--Oxygen hose, Acetylene hose, Twin hose
Hose Protection:
Plastic Hose Guard
Silicone Fire Sleeve
Nylon Braided Sleeve
Hose Ferrule:
For SAE 100R1AT/EN 853 1SN,1ST, EN857 1SC Hose
For SAE 100R2AT/EN 853 2SN,1ST, EN857 2SC Hose
For SAE R9, R12, R13, DIN EN 4SP, 4SH
For SAE R7, R8, and kind of other hose
Hose Fittings:
1) Material: Carbon steel, Stainless steel
2) Finish: yellow Zinc plated, White Zinc Plated
3) Standards: SAE, JIC, BSP, NPT, DIN, etc
Company Profile
1. Company Name: JUYE JINTONGDA PIPE INDUSTRY CO., Ltd
2. Date of establishment: 1999 (25 years experience in rubber hose&fitting)
3.Main products: hydraulic hose, welding hose, oil hose, fitting, etc.
4.Location: Qingdao,China, closed with the seaport
5.Outstanding R&D engineers team.
6. ISO9001 approved production process
7. 36 steel braiding machine, 4 spiral machines, 16 high-speed stranding machine and 6 vulcanization.
8. Annual production capability is 10 million meters around Exhibition Factory Tour We have our own laboratory equipped with all the equipment needed for product testing.
Such as I. D. /O. D. Check, impulse test continuously and rubber tensile/hardness testing.
The pulse count of our hoses can reach at least 200,000 times.
Our hoses can maintain their flexibility (elasticity, flexural and tensile strength) at temperatures as low as -55°C and can easily withstand temperatures up to +100°C. Product Packaging Certifications FAQQ1. Who is Juye Jintongda?A: We are a professional manufacturer of hydraulic hose and industrial hose with various specifications from 1999. We integrates the Research & Development, Production, Sales Export and focus on the high quality products all the time.
Q2. Please, do you have OEM service?A: Yes, we have OEM service.Q3. Can you produce according to the samples?A: Yes, we can produce by your samples or technical drawings.Q4. What is your sample policy?A: Usually the sample is free of charge, but the customers have to pay for the freight charge.
Q5. What is your terms of packing?A: Generally, we pack our goods in neutral white wearable woven bags. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.Q6. What is your payment term?A: T/T 30% in advance, and 70% before delivery or against copy of documents.Q7. What is your delivery term?A: EXW, FOB, CFR, CIF,etc.Q8. How about your delivery time?A: Generally, it will take 20 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.Q9. Please,do you have quality certificate?A: Yes, we have ISO 9001, SGS, CE and related test report.Q10. How long can you guarantee the goods?
A: We guarantee the goods one year.Q11. Please, do you test all your goods before delivery? A: Yes of course, we have 100% burst pressure test and impulse tests before delivery.
