915MHz Magnetron 5kw
| US$4,000.00-6,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
ACME-147
Installation
Plug-in Triode
Working Frequency
915MHz
Power Level
High Power
Function
Power Triode, Switching Triode
Structure
Alloy
Material
Germanium
Input
220V/380V
Input Mode
1 Phase 2 Wires/3 Phase 4 Wires
Power
5kw
Output Frequency
2450MHz
Efficiency
90%
Duty Cycle
0-50%
Transport Package
Wood Packing
Specification
5kw
Trademark
ACME
Origin
Jinan
HS Code
8540710000
Production Capacity
300PCS/Month
Packaging & Delivery
Package Size
20.00cm * 20.00cm * 20.00cm
Package Gross Weight
5.000kg
Product Description
Product introductionThe tube is a fixed frequency continuous wave magnetron with a wavelength of 12cm, which can directly excite the rectangular waveguide for microwave heating as a power source.
Main performance
Frequency 915 ± 25MHz
Output power ≥ 5kw
Anode voltage 6.5kv
Anode current 1.3A
Filament current 35a
Filament voltage 10V (subject to filament current)
The magnetic field is about 1450gs
Load voltage standing wave ratio ≤ 2
Limit service value
Filament surge current < 35A
Cathode preheating time ≥ 60s
Anode current ≤1.3a
Anode input power ≤ 5kw
Load voltage standing wave ratio ≤ 2.5
Anode temperature (designated test point) ≤ 100 ºC
Cathode outlet temperature (designated test point) ≤ 150 ºC
| Code | Min | Normal | Max |
| A B C | 110 φ83.8 | 112 φ84 - | 114 φ84.2 φ128 |
| D E F | - - - | φ76 - - | - φ35 φ56 |
| G H I J K L M N O P | - - - - - - - - - - | 176 56 135 φ106 φ70 450 10 10 15° 6×M6 | - - - - - - - - - - |
