120mm Bimetallic Injection Molding Machine Screw& Barrel for Recycled PP with 15% Glassfiber

Product Description

Detail Information For 120mm Bimetallic Injection Molding Machine Screw& Barrel:
Application: for recycled PP with 15% glassfiber.
Customer's Requirement: top abrasive resistance, long working life.
Screw's quality: bimetallic screw, screw's alloy layer contains 30% tungsten carbide powder.
Barrel's quality: OLIN-AR02 bimetallic barrel, better abrasive resistance, medium corrosive resistance.
Detail Information For All Brand Injection Molding Screw and Barrel:
Brief introduction:
it can be used in vertical& horizontal type injection molding machine, has different quality for different working sotuation, we can design it according to different material or customers'requirements.
Specification:
Diameter: Ø20mm-Ø300mm
Clamping force: 100KN-35000KN
Shot weight: 30g-30000g
Quality:
there are many different quality can be chosen, from normal nitriding quality to best abrasive& corrosive resistance, welcome to contact us.
Heat treatment:
Advance hardening and tempering
Nitriding treatment
Mid/high-frequency quenching
Vacuum hardening
Technical Parameters:
Nitriding depth: 0.50mm-0.80mm
Nitriding hardness: HRC56-58
Surface roughness: Ra 0.4
Screw straightness: 0.015mm
Alloy layer depth: 3mm
Hardness for alloy layer/ fully hardened screw: HRC56-64
