Yaomatec PVC Pipe Fiber Laser Marking Machine PVC Pipe Printer PVC Label Printer

Product Description

Yaomatec pvc pipe fiber laser marking machine pvc pipe printer pvc label printer Product Parameters

type	fiber-optic laser
wavelength	1064nm
average output power	≥30W@50kHz
Output port spot size	5-9mm
pulse repetition frequency	20KHZ-80kHz
Power stability (average power)	<3%
Pulse Width	150-190ns
master control	10.1 inch external controller
operating system	UNIX system
Marking speed	>=7000-8000mm/s(high speed>=10000mm/s)
mark character speed	300 characters/s, Roman font, character height 1mm
resolution	3-5μm
Marking accuracy	≤3-5μm
Minimum marking line width	≤10μm
mark depth	≤1mm(Depends on material)
Font type	Built-in multiple font effect options, fonts can be edited
Font effects	Dot matrix or line printing effect, you can edit and modify the font by yourself
Minimum character height	≤0.5mm
Marking range	Focusing lens F=160mm, range 100×100mm (standard), optional range 0-800mm
working focal length	180mm±2mm(160focusing lens)
multi-languages	English, French, Spanish, German, Chinese, Russian, Arabic, etc.
Administrative permissions	Multi-user management permissions
reserved signal	Start printing, printing status, printing completed, fault alarm
Data protection	With power-off data protection function
Missed dose monitoring	Provides overspeed alarm function due to false triggering due to material reflection
Remove intersection	Automatically remove intersection points and avoid key points of intersection
Coding software	Can realize single and double machine code sending
Laser type/wavelength	Red light preview, dual red light positioning focus, wavelength 1064nm
cooling method	air cooling
rated power	0.5KW
Power requirements	220V/single phase/50Hz/600W
ambient temperature	18-35ºC
Maintenance method	Lifelong maintenance-free
Industrial protection	IP54
Support printing information	Can print text information, variable information, serial number, batch number, bar code, QR code, micro-label and pattern. There are no restrictions on the number of lines and font size of information printed.
Applicable materials	Mainly used in 3C industry marking, white goods, electrical casing marking, flying marking of food and drug production dates, surface layer removal of 3D printing materials and other fields.

Packaging & Shipping

Package details:
Laser host Lens cap
Hexagon tool
Instruction manual
Rotating bracket
Power Cord 10-inch controller
Controller connection cable
Differential synchronizer long bracket
Digital display electric eye
M6 * 12 screws
M 5 x 25 screws
M 5 * 12 screws
M 4 * 8 screws
SHIPPING:UPS 1,UPS shipping: 7-15 days arrive
2. Delivery time: 3- 5 days

Note: don't include import taxes
1,we only charge
printer price and freight cost
2,please confirm you have the ability of custom clearance about the printer before buy it. it'sbetter use company name to receive.
PAYMENT: support pay through ******, TT bank transfer, Western Union
Detailed Photos
