Z/1100 Two Platen Injection Molding Machine/Production Line

Z/1100 Two Platen Injection Molding Machine/Production Line

US$10,000.00-400,000.00 1 Set (MOQ)

Basic Info.

Model NO.
Z/1100
Plastic Type
Thermoplastic, Tube Head Injection
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Plasticizing Capacity(G/S)
793
Distance Between Tie Bars(Width)(mm)
1260 mm
Ejector Force(Kn)
248 Kn
Open Stroke(mm)
1950 mm
Oiltank Cubage
1500 L
Screw Speed (Rpm)
0 - 90 Rpm, 90
Injection Weight (PS)
4796/5242/5708/6193 G
Theoretical Shot Volume(Cm3)
5270 Cm3
Warranty of Core Components
1 Year
Screw L/D Ratio
23, 23/22/21.1/20.3
Screw Diameter (mm)
110 mm
Plastic Processed
PP, PC, ABS, PPR, HDPE, Mlldpe, PA, Polystyrene
Screw Diameter
110/115/120/125 mm
Mold Height(mm)
450 - 1200 mm
Power (Kw)
66.1 Kw
Specification
New
Trademark
AOTAI
Origin
Zhejiang, China
Production Capacity
500 Set/Sets Per Year

Product Description

Z/1100 Two Platen Injection Molding Machine/Production Line
Product Description
Specification
Machine model
Z/1100
Screw type
A
B
C
D
Screw diameter (mm)
110
115
120
125
Screw L/D ratio (L/D)
23
22
21.1
20.3
Shot volume (theoretical) (CM3)
5270
5760
6272
6806
Injection weight (PS)(g)
4796
5242
5708
6193
Pump max.pressure (Mpa)
21/16
Pump motor power (servo)(KW)
45+55+7.5
Number of heating area(Segment)
6+1
Machine dimension (L*W*H) (M)
9.5*3.3*3.4



1. What kind of plastic material can be used on this machine?
PP, PE, PS, ABS and other general material could be used on this machine.
If you have other special material such as PC, PMMA, PVC, please contact us for further information. 2. What is guarantee time for this machine?
12 months after installation or 18 months again B/L date.
3. What kind of shipping container for this machine?
Containere choose will depends on the different machine size . 20HQ,40HQ,40GP will suitable for different size machine.
4. How much is Engineer service charge?
We can send experienced technician to customer's country for guiding the installation and commission the machine, also train the
customer's employee. Customer need to afford technician visa charge, round trip air ticket expense, accommodation and
transportation in local. Also customer needs to pay USD 80 per days to technician as salary.
5. How long will be for installation and commission this machine?
If customer prepare all necessary thing such as power supply, water supply, hydraulic oil, plastic material, plastic mold,
installation and commission period will be within 7days including training customer's employee.
6. How many workers are needed to operate this machine?
One worker only.
7. What is the power consumption for this machine?
Power consumption is determined by the product. Different product requests different power consumption.
