Desktop Optical Switch with Low Loss for Optical Protection System
| US$500.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
Desktop Optical Switch
Certification
ISO, RoHS
Condition
New
Quality Control
100% Testing Before Shipping
Transport Package
Box
Specification
Small
Trademark
ZG
Origin
Mianyang, China
Product Description
FeaturesEasy to use&good layout
High reaction speed,high- speed awitching
Detachable input&output for easy cleaning
Low loss,high channel isolation
Applications Product Description
Company Profile
Passive optical network
Optical Protection System
Measuring System
Network monitoring
| Wavelength(nm) | 850/1064/1310/1550nm | |
| Insertion loss(dB) | 1.2 (4 Channel) 2.0 (8 Channel) | |
| Number of switching channels(pcs) | 1-8 ,Customizable | |
| Maximum output optical power(mW) | >200 | |
| Channel crosstalk(dB) | >50 | |
| Channel return loss(dB) | >50 | |
| Switching repeatability(dB) | 0.03 | |
| Switching time(ms) | 10 | |
| Communication connector | RS232 | |
| Working power supply | 220V | |
| Operating temperature (ºC) | -10~+40 | |
| Storage temperature(ºC) | -25~+70 | |
| Host weight (kg) | 2 |
