High Efficiency 4000W 24V 36V 48V 70V 110V 220V Se Series Adjustable AC to DC Industrial SMPS Switching Power Supply
| US$314.29 | 1 Piece (MOQ) |
Basic Info.
Model NO.
SE-4000
Output Power
4000W
Input Voltage
180-264VAC/245-370VDC
Certification
CE
Brand
Weho
Startup & Rise Time
1500ms, 30ms/230VAC
Efficiency
90%
Frequency Range
45Hz -65Hz
Input Current
29A/115VAC;18A/230VAC
Leakage Current
<3.0mA/240VAC
Short Circuit
Enter Constant Current
Analog Voltage Control
0-5V/0-10V Control (Voltage, Current)
Auxiliary Power Supply
12V 0.5A
Net Weight
4.1kg
Transport Package
Carton
Specification
300*200*70mm(L*W*H)
Trademark
WEHO
Origin
Zhejiang
HS Code
8504401400
Production Capacity
500000
Packaging & Delivery
Package Size
30.00cm * 20.00cm * 7.00cm
Package Gross Weight
4.100kg
Product Description
High Efficiency 4000W 24V 36V 48V 70V 110V 220V SE Series Adjustable Ac to Dc industrial Smps Switching Power Supply Detailed Photos Notice:1.Analog voltage control
2.External main switch controt
3.Voltage and current adjustable
4.SCP/OTP
Product Parameters
| Model | SE-4000-12 | SE-4000-24 | SE-4000-36 | SE-4000-48 | SE-4000-72 | SE-4000-96 | SE-4000-110 | SE-4000-150 | SE-4000-220 | |
| Output Characteristics | DC output voltage | 12V | 24V | 36V | 48V | 72V | 96V | 110V | 150V | 220V |
| Rated current | 290A | 166.7A | 111A | 83.3A | 55.6A | 41.7A | 36.4A | 26.7A | 18.2A | |
| Current range | 0-290A | 0-166.7A | 0-111A | 0-83.3A | 0-55.6A | 0-41.7A | 0-36.4A | 0-26.7A | 0-18.2A | |
| Rated Power | 4000W | |||||||||
| Ripple | 250mV | 270mV | 300mV | 400mV | 500mV | 600mV | 850mV | 900mV | 1000mV | |
| Constant current optimum range | 6-12V | 12-24V | 18-36V | 24 -48V | 36-72V | 48-96V | 55-110V | 75 -150V | 110-220V | |
| Voltage accuracy | ±1.0% | |||||||||
| Line Regulation | ±1.0% | |||||||||
| Load Regulation | ±1.0% | |||||||||
| Startup & Rise Time | 1500mS,100mS/230VAC(Fully loaded) | |||||||||
| Input characteristics | Input voltage | 180-264VAC/245-370VDC | ||||||||
| Frequency range | 45Hz -65Hz | |||||||||
| Power Factor | PF≥0.65/230VAC(Fully loaded) | |||||||||
| efficiency | 83% | 86% | 87% | 89% | 90% | 90% | 90% | 91% | 91% | |
| AC Current | <30A | |||||||||
| Leakage Current | <3.0mA/240VAC | |||||||||
| Short Circuit | Enter constant current | |||||||||
| Over temperature | Shut down the output, and automatically recover or restart after the temperature drops | |||||||||
| Protection features | Output voltage adjustment | 0-13.2V | 0-26.4V | 0-39.6V | 0-52.8V | 0-79.2V | 0-105.6V | 0-121V | 0-165V | 0-242V |
| Output constant current adjustment | 0-290A | 0-166.74A | 0-111A | 0-83.3A | 0-55.6A | 0-41.7A | 0-36.4A | 0-26.7A | 0-18.2A | |
| External potentiometer | External potentiometer control (voltage, current) | |||||||||
| Analog voltage control | 0 - 5V/0 - 10V control (voltage, current) | |||||||||
| Auxiliary power supply | 12V 0.5A | |||||||||
| Remote control switch | Default power on, high level power off (3V-12V) | |||||||||
| Environmental characteristics | Operating temperature | -20-+60ºC | ||||||||
| Operating humidity | -20-90%RH without condensation | |||||||||
| Storage temperature/humidity | -40-+85ºC,10-95%RH without condensation | |||||||||
| Vibration resistance | 10-500Hz, 2G 10 minutes/cycle, 60 minutes for each of X, Y and Z axes | |||||||||
| Safety and electromagnetic compatibility | Insulation resistance | Input to output: 100Mhms/500VDC/25ºC/70%RH | ||||||||
| Pressure resistance | I/P-0/P:1.2KVAC I/P-FG:1.2KVAC 0/P-FG:0.5KVAC | |||||||||
| Product size | 300*200*70mm(L*W*H) | |||||||||
| Net weight | 4.1 KG | |||||||||
| Remark | 1. All parameters are measured at 230VAC input voltage, rated load and 25ºC unless otherwise specified. 2. Ripple and noise voltage are measured with a 20MHz bandwidth oscilloscope with 0.1μ and 47μ capacitors added to the end of a 12-inch twisted pair, and measured at 20MHZ bandwidth. 3. Accuracy: includes setting error, linear regulation rate and load regulation rate. 4. Output must be derated in low input voltage conditions, please refer to the static characteristic curve for details. 5. Startup time is measured under cold start, and frequent switching may increase the startup time." | |||||||||
Packaging & Shipping Application Certifications FAQ Q1:Are you a factory or trading company?
A1:We are factory.
Q2:Why choose us?
A2:Our factory has been in operation for 17 years,We have enough experience to meet your needs.
Q3:How can I get the samples?
A3:You can pay for the sample this time, and we will refund the sample fee for the next batch order.
Q4:How to order?
A4:Please contact us online to send you a proforma invoice or send us your purchase order by email.
Q5:How many years warranty of your products?
A5: 1 years
