Professional Superfine Mesh Cotton Fiber Hammer Mill

Professional Superfine Mesh Cotton Fiber Hammer Mill

US$15,000.00 1 Set (MOQ)

Basic Info.

Model NO.
JMJ
Processing Object
Animal-Derived Feed
Processing Technics
Crushing-before-Mixing
Screen Mesh
With Screen Mesh
Grinding Equipment Type
Roll Crusher
Pellet Mill Type
Screw Granulator
Bulking Machine Type
Twin Screw Bulking Machine
Expanding Method
Dry Expansion
Condition
New
Applicable Materials Shape
Short strip
Warranty
12 Months
Main Material
Carbon Steel or 304 Stainless Steel
OEM&ODM
Available
Spare Parts
Available
Famous Brand Motor
Available
Knife Material
From Germany or Japan
Transport Package
Wooden Pallet
Specification
ISO9001
Trademark
OEM
Origin
China
HS Code
8479820090
Production Capacity
50 Set/Month

Product Description

JMJ-500 Professional Superfine Mesh Cotton Fiber Hammer Mill

Working Principle Material through Belt conveying machine sent to (in belt sent material of while for metal detection, prevent material in the entrainment metal debris) plus hopper Hou quickly is high-speed air with into dynamic knife ,high-speed rotating of rotor led dynamic knife by produced of powerful ,and full dispersed reached Super fine cut crushed of effect, qualified material through sieve network discharge area,unqualified material will be grinded ; To reach the required fineness of the materials and production, you can replace the screen, adjust the cutter clearance or different numbers of knives.
Technical Parameter

Model
JMJ-500
Rotor Diameter(mm)
500
Knife length(mm)
1000
Rotor Speed(r/m)
750~1100
Fineness(mesh)
20~325
Capacity(kg/h)
50~500
Power(kw)
75
Outline dimension(mm)
2410*1900*2780

Note: 1, crushing fineness and yield changes depending on the material of a different nature;
2, the speed of the equipment according to the nature of material.
Flow Chart ( JMJ-500)


Related Engineering Cases
Technical support
Upon receiving the deposit, we will offer the following technical services:
1. Design for your production line flow and equipment layout, free of charge;
2. Provide foundation drawings of customer-ordered grinding mills and drawings of related parts, etc;
3. Technical parameters of peripheral equipment will be supplied;
4. Free technical suggestions on adjusting of equipment layout and application.
5. Equipment upgrading (customers need to pay the cost);
Quality assurance
1. Strictly conforming to ISO9001-2000 quality management system;
2. Strict control from purchasing inspection, process inspection to final proofing;
3. Established several QC departments to execute quality control regulations;
4. Detailed quality control examples:
(1) Complete files for quality control and quality feedback;
(2) Strict inspection for the components of our grinding mills, to assure products free of damage and avoid rust-eaten and paint peeling off later on.
(3) Only qualified components will be assembled and total equipment must be inspected completely before sale.
After sale service
1. We will send our technician to the site for guiding equipment installation and commissioning.
2. During the installation and commissioning, we offer operator training service.
3. The quality assurance date is one year after commissioning. And after that, we will collect the cost if provide repairing for your equipment.
4. Maintenance for equipment failure caused by improper handling (appropriate cost will be collected).
5. We offer the components with favorable price and perdurable maintenance.
6. If equipment repairing is needed after quality assurance date is expired, we will collect maintenance cost.
