63mm 2.5inch Steel Case Pressure Gauge Manometer

Product Description

Application:
For corrosive or non corosive gas and liquid aggressive Media which are not highly viscous and would crystallize.
Particularly used in chemical, petrochemical and food Industry, biochemistry and any rush industries. For Measuring points subject to vibrations and high dynamic Pressure load.
*Specification:
1. Case: black steel
2. Window: Acrylic(dial size: 1-1/2"~3") Safety glass(dial size: 4"~6")
3. Element & Movement: brass
4. Bourdon tube system: brass
5. Socket: brass
6. Pointer: Aluminum alloy, black painted
7. Connection: 1/8", 1/4", 3/8", 1/2", 3/4"(BSP(PF)/BSPT(PT)/NPT)
8. Connection type:
A type(button connection),
B type(button connection with back flange for wall
Mounting)
AD type(back connection without flange)
BD type(back connection with front flange)
UD type(back connection with clamp(w/o flange) for panel
Mounting)
9. Dial size: 1.5", 2", 2.5", 3", 4", 6"
10. Ambient Temperature: -20~60C
11. Measured medium temperature: Tmax. +100C
12. Accuracy: (+/-)1.6% full scale(dial size: 1.5"~2.5")
(+/-)1.0% full scale(dial size: 3"~6")
13. Pressure range: Depand on your order
14. Type: Standard pressure gauge; Vacuum pressure gauge &Compound pressure gauge
Options:
>>Safety glass window for dial size: 2.5"&3"
>>Blow-out disk by back for dial size: 4"
>>Adjustable pointer available for dial size: 4"&6"
>>Special male or female thread connections
>>Measured medium Tmax. +100C
>>Glycerine or Silicone filling
>>Cleanness for oxygen service
>>Red pointer indicating max. Pressure on dial

Nominal Size :	2.5"(63mm),4.0"(100mm),6.0"(150mm)
Pressure Range :	0-100psi
Accuracy :	±1.6%, ±2.5%
WorkingTemperature:	-20°c~40°c
Case:	black steel
Bezel :	brass
Bourdon tube :	brass ≤ 60 bar: C-type > 60 bar: Helical type
Connection:	brass
Movement:	brass
Dial:	Aluminium
Pointer:	Aluminium ,black
Window:	Glass Or Plastic
Thread:	1/8",1/4", 3/8",1/2", PT,BSP,NPT etc.
Fill:	Glycerine(standard) Silicone(optional)
Gaskets/Filling cap:	Neoprene Or Silica gel
