Basic Info.
Certification
CE, ISO 9001
Maximum Working Height
8m
Maximum Platform Height
6m
Overall Height (Rail Unfolded)
1860mm
Working Platform Size
1670X740mm
Platform Extension Size
900mm
Machine Running Speed (Retraction)
3.5km/H
Machine Running Speed (Lifting)
0.8km/H
Transport Package
Container
Specification
1860mm*760mm*1840mm
Production Capacity
100pieces/Month
Product Description
Product Description
Model Specification | EPT1416 | EPT1214 | EPT1012 | EPT0810 | EPT0810NP | EPT0608 |
S.W.L | 230Kg | 320Kg | 320Kg | 450kg | 320Kg | 450Kg |
S.W.L On Extension | 110Kg | 113Kg | 113kg | 113Kg | 113Kg | 113Kg |
Max. Occupants Indoor/Outdoor | 2 | 3 | 3 | 4 | 4 | 4 |
Max. Working Height | 15.8m | 13.8m | 12m | 10m | 10m | 8m |
Max. Platform Height | 13.8m | 11.8m | 10m | 8m | 8m | 6m |
Overall Length | 2850mm | 2430mm | 2430mm | 2430mm | 2430mm | 2430mm |
Overall Width | 1310mm | 1210mm | 1210mm | 1210mm | 890mm | 1210mm |
Overall Height(Rails Up) | 2620mm | 2600mm | 2470mm | 2350mm | 2350mm | 2220mm |
Overall Height(Rails Down) | 2060mm | 2060mm | 1930mm | 1800mm | 1800mm | 1670mm |
Platform Size | 2700X1110mm | 2270*1120mm | 2270X1120mm | 2270X1120mm | 2270X860mm | 2270X1120mm |
Platform Extension Size | 900mm | 900mm | 900mm | 900mm | 900mm | 900mm |
| | | | | | |
Detailed Photos
Installation Instructions
Packaging & Shipping
In order for our customers to receive new and intact goods, we will check the products many times before delivery, and carry out multiple layers of protection and reinforcement.
Company Profile
1. Large scale company:Our company has an area of 40,000 square meters, factory area of 30,000 square meters and nearly 300 employees. 2.We have a lot of experience :More than ten years of export and production experience.
3.Diversified products : Jiangsu Everstar International Trade Co., Ltd. is a national high-tech enterprise specialized in the research, development, production, sales, export and service of multi- functional slip-form paver,water well drilling rig, aerial platform truck, ladder truck, highway guardrail pile driver, solar pile driver, hydraulic earth auger, piling rig spare parts and other equipment.
4.Complete patent certificate :Our company has an area of 40,000 square meters, factory area of 30,000 square meters and nearly 300 employees. Our product sales and market share have been far ahead in the industry. We fully implement the standard implementation work, currently we have 4 invention patents, 51 utility model patents, 15 appearance patents, we strictly implement the ISO9001 standard management, we are the first one who adopts refined assembly line in our industry, all products have passed the CE certification. At the same time, we have passed the strict national environmental protection certification- China Quality Certification Center Products Mandatory CCC Certification.
5.Warranty after sale is worry-free :After-sales staff 24 hours online service for you.
