Swivel Head Knee Type Vertical Metal Drilling Milling Machine
| US$1,800.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
ZX7550CW
Type
Worktable Milling Machine
Object
Hardware
Structure
Lifts
Milling Cutter Type
Cylindrical Milling Cutter
Milling Cutter Structure
Indexable Type
Controlling Mode
Artificial
Automatic Grade
Semiautomatic
Precision
Precision
Certification
GS, CE, ISO 9001
Condition
New
Transport Package
W/Case
Specification
1250X360
Trademark
Allway
Origin
China
HS Code
84592900
Production Capacity
1000PCS/Year
Product Description
The main performance characteristics: 1 Universal use as milling machines and drill press
2. Easily shiftable gear drive ensures power transmission without losses
3. With v-belt spindle drive
4. Head swivels into the horizontal level on both sided via crank and toothed gear, easy activation of manual micro-feed for the spindle quill
5. Spindle and quill with large diameter, radial and axial bearing allows use for milling machines
6. Milling table swivels horizontally, including scale
7. Dovetail guides on all 3 axes
8. Head, table height can be adjusted through gear rack
9. Forward/reverse setting through motor switch Application: Widely used in single or batch is machinery manufacturing industry; instrument; building decoration and repair department. Product Parameters
Product main technical Specifications:
| SPECIFICATIONS | Units | ZX7550CW |
| Max. drilling dia. | mm | 50 |
| Max. end milling dia. | mm | 100 |
| Max. vertical milling dia. | mm | 25 |
| Max.boring dia. | mm | 120 |
| Max. tapping dia. | mm | M16 |
| Distance between spindle nose and table surface | mm | 90-490 |
| Spindle taper | - | MT4( V/ H) |
| Spindle speed range | rpm | 40-1400(V) 80-1300(H) |
| Spindle travel | mm | 120 |
| Table size | mm | 1000*240 |
| Table travel | mm | 600*240 |
| Table feed speed | mm/min | X: 15-490 |
| Main motor power | kw | 1.5/2.2( V)2.2( H) |
| Machine weight | kg | 1000 |
| Overall dimensions | mm | 1400*1300*2080 |
