US$4.00-9.50
|
500 Meters
(MOQ)
|
Basic Info.
Model NO.
customized profile
Water Absorption
0.1%~0.3%
Contraction Percentage
<0.4%
Tensile Strength
81~130MPa
Production Capacity
100 Million Meters
Product Description
Product Name | Fiberglass Skylight Roofing Sheet |
Resin Ingredient | Advanced benzene-----new neopentyl glycol anti-ageing DTM-1 resin. |
Surface Treatment | Surface applying Morplated anti-ageing glue (80 µm thickness or so) and pastes Melinex 301. |
Glass Fiber | Adopting Taian high- quality glass fiber, the content no less than 30%. |
Unit Weight | 1800g/m² 2400g/m² 3050g/m² |
Nominal Thickness | 1.2mm 1.5mm 2.0mm |
Heat Resistance Limit | -60 to +130 |
Light Transmittance | 75%±2% ( light green) 53%±2% (cream white) |
Anti- ultraviolet Rate | 99.9% |
Tensile Strength | 100Mpa |
Flexural Strength | 180Mpa |
Cracking Elongation Rate | 1.9% |
Barcol Hardness | ≥50 |
Thermal Expansion Coefficient | 2.2×10¯5cm/cm/ |
Thermal Conductivity | 0.18w/m° k |
Warranty | 10 years |
* Good No cracking phenomenon when driving nails in roof installation * Having close combining with color steel plate. Cross- section thickness is uniform. The shape of FRP sheet is consistent with steel plate. * Transmittance loss rate is low. No yellowing phenomenon after long term service. * Thermal expansion coefficient is close to that of steel plate. No cracking and water leakage in nail driving place because of expand with heat and contract with cold. * Light through FRP sheet assumes scattering shape and gentle. * Bright and clean appearance, no distinct air bubble and cracking on FRP sheet. * Anti- ultraviolet and anti- chemistry corrosion. * Anti- ageing and anti- pulverization. * Long service life.
Q: Could you customize the size? A: We have standard thickness. We can customize the width, color and length. The length shall be less than the container length. We need you to send roof profile drawing to us. Q: What's your MOQ? A: 500 meters. Q: Could you recommend the model and quantity? A: Yes, we can design the model and quantity as per the warehouse dimension and warehouse type. Q:How about the lead time? A: Normally 2 weeks. It depends on the quantity and our production plan.
