Easily Operate Generator Diesel Generator Silent Type Generator

Product Description

Product DescriptionAn open type generator, also known as an open-frame generator, is a type of power generation equipment with the following characteristics and details:
Structure
• Open Frame Structure: It has a simple and exposed frame design without a fully enclosed casing. This allows for easy access to internal components like the engine and alternator, facilitating maintenance and repair.
• Engine: Usually gasoline or diesel engines are used. These engines provide the necessary mechanical power to drive the generator. The engine is equipped with components such as an air filter, fuel system and cooling system to ensure stable operation.
• Alternator: Connected to the engine, it converts mechanical energy into electrical energy. It consists of components like coils and magnets.
Working Principle
• Energy Conversion: The engine burns fuel to produce mechanical energy through combustion. The alternator then uses electromagnetic induction to convert this mechanical energy into electrical energy, which is output through terminals for use by external devices.
Applications
• Construction Sites: Commonly used on construction sites to power tools and equipment like concrete mixers, power saws and lighting, as it can meet the high-power requirements.
• Outdoor Activities: Suitable for outdoor activities such as camping and RV trips, providing power for lighting, charging electronic devices and running small appliances.
• Temporary Events: At temporary events like outdoor concerts and fairs, open type generators can supply power for sound systems, lighting and food stalls.
Advantages
• Cost-Effectiveness: Generally, open type generators have a relatively lower manufacturing cost compared to enclosed ones, making them more affordable for some users with limited budgets.
• Good Heat Dissipation: The open structure allows for better air circulation, which is beneficial for heat dissipation and helps to maintain the normal operating temperature of the generator.
• High Power Output: They can often provide relatively high power output to meet the needs of different power-consuming equipment.
Detailed Photos

water tank	Diesel Pump	Return Line
Air Filter Element	Four Protect System	Alternator
Intake Pipe	Starting Battery	Diesel Filter Element
Engine Base	Unit Nameplate	Air Swith
Oil Gauge	Turbo Charged Engine	Oil Filter Element
Battery Charger	Shock Absorber	Battery Breaker

Product Parameters

Generators set model	HL50GF	Speed mode	Electronic speed regulation
Prime power(KW)	50	Full load fuel consumptionrate(g/kwh)	202
Standby power(KW)	55	reference weight (Kg)	290
Unit capacity(KVA)	62.5	Fuel model	Domestic No. 0
Related speed (RPM)	1500	Coolant flow(m'/min)	/
Related voltage (V)	400	Gas volume(mmin)	/
Rated current (A)	90	Smoke exhaust(m³/min)	/
Related frequency(Hz)	50	Speed mode	/

Rated power factor	0.8	cooling method	Closed water cooling
Phase	3	Oil capacity(L)	102*120
Reference weight(Kg)	820	Coolant capacity (L)	3.9
Reference size (L x W x H)	1830*750*1200mm	reference weight (Kg )	350
Engine model	4BTA3.9-G2	Alternator model	HLF50
Engine related power (kw)	50	Rated voltage (V)	400
Engine standby power (kw)	55	Rated frequency(Hz)	50
Engine structural features	Four-stroke,turbocharged	Rated speed(RPM)	1500

Cylinders /arrangement	4 cylinders/in-line	Power factor	0.8
Bore *stroke(mm)	102*120	Phase and wiring	Three phase ,Y type
Displacement(L)	3.9	efficiency(%)	95.19
Compression ratio	17.3:1	Excitation method	Brushless excitation
Start method	Electric	Insulation class	H
		Protection level	IP23
