Container Car Carriage Panel Making Machines Floor Deck Roof Sheets Cold Roll Forming Machine

Product Description

Carriage Board Floor Deck
Roll Forming Machine

Production Information

Samples and Application
Automotive cabin panel equipment has a wide range of uses. It can be used for various types of vehicles such as automobiles, electric vehicles, and agricultural tricycles. It can also be used for automatic roll forming equipment for automobiles. It can also be used for automobile section steel production equipment in places such as automobile compartment columns, automobile bottom beams, automobile left and right rear panels, automobile front fenders, etc. and supporting installation equipment. At the same time, it can also be used for the production of floor decking for housing construction.

Working Flow

No	Item		Specification
1	Product name		Carriage Board Floor Deck Roll Forming Machine
2	Raw material	Material	PPGI GI
		Feeding width	As drawing
		Thickness	0.3-0.8mm
3	Decoiler	Operate	Hydraulic
		Weight capacity	5ton
4	Main forming machine	Roller station	18
		Diameter of shaft	80mm
		Roller material	High grade 45# steel
		Frame	Steel plate welder
		Cutting material	Cr 12
		Operation	Automatic cutting
		Working speed	15-20m/min
5	Power	Driving way	chain/Hydraulic
		Main motor	7.5kw
		Voltage	380V 50hz
6	Control system	Electric box	PLC control system
		PLC brand	DELTA

Precision Type hydraulic rolling mills and automobiles can generally be used for production line production, so that uncoiling, guiding leveling, automatic tracking and cutting to length can all be completed at one time.

Recommended Productionmore

Our company has been dedicated to foreign trade for many years. We can provide customized production equipment for various models of GI, GL, tinplate, metal carved board production line, metal fence roll forming machine machines,roof and wall panel roll forming machine and so on. They all are of excellent quality, aesthetically designed, and easy to use automation. If you need, please inquiry or purchase in advance. We can provide you with competitive prices.
We can produce various types: we can also design machines according to customer requirements, and you can send us your panel drawings

Company Information

Our company is located in Botou City, a famous casting city in China, in the Bohai Economic Circle. It is bordered to the north by Beijing Tianjin and to the east by Bohai Sea. National highways 104 and 106, the Beijing Shanghai Railway, and the Beijing Fuzhou Expressway run through the city, providing convenient transportation and superior location.

Our company's main products include: color steel plate equipment, glazed tile equipment, floor support plate equipment, C/Z steel forming equipment, composite machine forming equipment, automotive panel, dust removal anode plate and other equipment. We can customize production according to the actual needs of users, and provide a series of technical guidance for pre-sales and after-sales, as well as a one-stop service for production, installation, debugging, and maintenance.
Backed by reasonable design, precision machining and selected material, both our standard and customized machines are characterized by long life span, precise forming and easy operation. With our customers' trust, our machines have been sent to America, Australia, Russia, India, Sri Lanka, Nigeria, Pakistan, Uzbekistan, Mozambique, Angola, Turkey, Brazil, etc.
Warmly welcome to China to visit our factory and select the machines you need. Our address, Fuzhuang Industrial Development Zone, Botou City, Hebei Province, China

After Service

1. INSTALLATION AND TRAINING
· A.If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also train your workers/technician face to face.
· B.Without visiting, we will send you user manual and video to teach you to install and operate.
· C.lf buyer needs our technician to go to your local facto- ry, please arrange board and lodging and other neces- sary things.
2. AFTER SERVICE
· A.One year guarantee for whole machine.
· B.24 hours technical support by email or calling
· C.If there is any problem found of the machine, we will repair it for free in one year.
