High Precision Mini CNC Lathe Machine for Metal Process

Product Description

Product Description

KX-36J CNC LATHE MACHINE
Machinery Specification
	Specification			Parameter			Optional
LATHE	Slant bed degree			30°
	Clamping way			Hydraulic clamping
	Tool form			Row of knives
PART	Guide rail			Taiwan 25 Linear guideway
	Ball screw			Taiwan 25 ball grinding precision
	Bearing			7015/7013 XEZ
	Ground to spindle center height			1080mm
	Spindle motor			3.7kw DMC servo motor
	Feed servo			1.2kw DMC servo motor
	CNC Control System			NANJINGKT 820Ti			SYNTEC/GSK/LNC

Application scope of processing				Normal Use Value			Maximum Value
Working ability	Spindle bore			φ35mm			φ35mm
	Maximum particle diameter (disc type)			250mm			300mm
	Maximum length of workpiece to be processed			210mm			230mm
	Single side cutting of stainless steel			2mm			3mm
	Repositioning accuracy			±0.01mm
	Smooth finish			1.6RA
	Center height of tool rest			40mm
	Turning diameter			φ250mm
	Square tool specification			16mm
Travel	X axis travel			600mm
	Z axis travel			230mm
Feed	X-axis fast moving velocity			25m/min			30m/min
	Z-axis fast moving velocity			25m/min			30m/min
	X axis servo power			1.2KW
	Z axis servo power			1.2KW
Spindle	Spindle speed			3500r/min			4000r/min
	Spindle motor power			3.7KW
	Spindle nose			A2-4
	Support hydraulic chuck size			5 inch			6 inch
Dimensional & weight	Dimensions			2050*1530*1950 mm
	Weight			1800KG

Detailed Photos

Our Product Features


1. Adopting anti deformation patented heavy-duty base, with sufficient weight and support high-speed movement;
2. Adopting self-developed electronic control system to maximize the efficiency of electromechanical cooperation;
3. Sufficient weight to support vibration resistance during bar and large parts processing, improve accuracy and smoothness;
4. Key components adopt high-quality wear-resistant configurations such as Taiwanese brands, full dynamic balance for sleeve spindle installation.
Our Product Advantages



1. Fine Workmanship / Advanced Technology / Competitive Price
2. High Efficiency / High Accuracy / High Stability

3. High Level of Automation, Saving Manpower or Labors

4. A Wide Range of Applications (suitable for most regular / irregular shape hardware accessories such as copper, iron, aluminum, stainless steel material & hard plastic accessories)

5. Stable System

6. Easy to Operate and Safe

7. Stable and Reliable Processing Quality

8. Save Time and Improve Productivity

9. Beneficial to Modernization of Production Management

10. Durable & Low Maintenance Rate

* Last but not leastCost Effective & High Cost Performance

Major Optional Devices
We have a very professional team from product design, R&D, manufacturing, marketing, technical training, and after-sales service, with standardized production technology to ensure the quality of products for customers.

We also have a professional after-sales team, so that every customer can have good product experience and after-sales service after receiving the product.









Company Profile

Foshan Shunde XinLongKe Automation Technology Co., Ltd (NEORONKO) is one of the fastest growing CNC machine manufacturers, located in Shunde District, Foshan City, Guangdong Province, South China since 2015. Our company XinLongKe / NEORONKO is a wholly-owned subsidiary of Guangdong YASHU Intelligent Technology Co., Ltd, who has been listed on China stock market since February 2023 (Stock code: 874026).

Our company team has more than 20 years of experience in the development and production of senior CNC systems and over 40 years of experience in mechanical design and production. So far, our products have acquired quality system certificates such as CE, EAC (for Russia market), NOA, etc. Over the years, we have successively obtained related patented technologies and software copyrights for multiple core components.

We are equipped with advanced production line, equipments and technology, with monthly production capacity more than 400 sets of CNC lathe machines for clients from home and aboard.
Our main products include small CNC lathes, small CNC turning and milling composite machines, small CNC machining centers, CNC cam lathes, and other intelligent CNC industrial master machines that apply independent intellectual property CNC systems. Our products are widely applied in industries such as 3C ( Computers/Communications/Consumer Electronics) / new energy / hardware products / home appliance manufacturing / home decoration building materials / automotive parts / general equipment.


Certificates/Patents/Honors & Awards



Note: Our company XinLongKe / NEORONKO is a wholly-owned subsidiary of Guangdong YASHU Intelligent Technology Co., Ltd, who has been listed on China stock market since February 2023 (Stock code: 874026).
Our Workshop
Exhibition
Packing & Delivery

FAQ
1. How can I get the price?
Answer: We usually quote within 24 hours after we get your inquiry (Except weekend and holidays). If you are very urgent to get the price, please email us or contact us in other ways so that we can offer you a quote.

2. How can I choose the most suitable machines ? Answer: Please tell me your specifications, we can choose the best model for you, or you can choose the exact model. You can also send us the product drawings, we will choose the most suitable machines for you.

3. Can I place Metalworking samples orders?
Answer: Yes. Please feel free to contact us.

4. What is your lead time?
Answer: It depends on the order quantity and the season you place the order. Usually we can ship 1-2 machine in 30 working days ; For more than 3 machines, about 35 working days.

5. What is your payment term?
Answer: T/T or ****** Trade Assurance Order Service, other payment term need to be discussed.

6. What is the shipping method?
Answer: Machine order shipped by sea or land transportation ; Metalworking samples by express (EMS/UPS/DHL/TNT/FEDEX and ect). Please confirm with us before placing orders.

7. What is the form of after-sales service?
Answer: a. Warranty is one yearJust for parts. There is no visiting repairing, We offer video support and send the parts for repairing.

-b. Sample making shall be conducted before order if required, i.e. the buyer shall pay the sample making fees first.

-c. Manufacturer shall do the testing and commissioning for the goods before shipment.

-d. After shipment, buyer can go to local maintenance if technical issues occurred (Manufacturer will be responsible for sending spare parts if buyer need. )

-e. Spare parts such as belt, chuck, screw & nuts, hydraulic oil, working lighting, cutting tool, etc are not under warranty scope.

8. How do you make our business long-term and good relationship?
Answer: We keep good quality and competitive price to ensure our customers benefit. Furthermore, we respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
