Basic Info.
Application Area
Agricultural Chemicals
Cooling Method
Air Cooling
Heating Method
Electric Heating
Main Material
Carbon Steel
Mixing Drum Shape
Long Slot
Tank Dimensions
9900X500X2200mm
No. Workstation
4 Workstations
Distance Between Stations
2.3m
Supporting Equipment
Full-Automatic Packing Machine
Shell Material
Carbon Steel Plate
Transport Package
Export Wooden Cases
Packaging & Delivery
Package Size
1000.00cm * 55.00cm * 55.00cm
Package Gross Weight
2955.000kg
Product Description
Product Description
Mushroom distributor, built-in twisted-dragon, to achieve mixing + storage function at the same time, the mushroom material through the feeding port into the bagging machine, excess material is returned to the secondary mixer through the conveyor, no hoarding and accumulation phenomenon. Suitable for medium and large mushroom planting base annual production use.
Main features:
1. Efficient and stable: Adopting advanced design to ensure smooth machine operation and high material separation efficiency.
2. Easy to operate: The structural design is reasonable, the operation is simple and fast, and it is convenient for users to use.
3. Customized services: Flexible customization according to user needs to meet different production requirements.
Detailed Photos
STRUCTURE OF MUSHROOM DISTRIBUTOR |
Material box: used to store mushroom materials to be mixed and distributed.
Conveyor device: Use a conveyor belt to transport mushroom material from the bin to the mixing position.
Discharge outlet: The mushroom material is fed into the bagging machine through the discharge port.
Mixing device: thoroughly mix the mushroom material before distribution.
Control device: equipped with automatic control function to achieve more precise operation.
Product Parameters
Number of stations | Specifications | Dimensions of groove | Height above ground | Motor Power | Weight | Dimensions |
3 Work stations | 1500mm | 690x450mm | 1700mm | 4KW | 1715kg | 6000x450x1700mm |
2500mm | 880x500mm | 2200mm | 5.5KW | 2500kg | 7600x500x2200mm |
4 Work stations | 1500mm | 690x450mm | 1700mm | 4KW dual motor | 2065kg | 7500x450x1700mm |
2500mm | 880x500mm | 2200mm | 7.5KW dual motor | 2950kg | 9900x500x2200mm |
5 Work stations | 1500mm | 880x500mm | 1700mm | 5.5KW dual motor | 2635kg | 9000x500x1700mm |
2500mm | 880x500mm | 2200mm | 7.5KW dual motor | 3428kg | 12200x500x2200mm |
6 Work stations | 1500mm | 880x500mm | 1700mm | 5.5KW dual motor | 3715kg | 10500x500x1700mm |
2500mm | 880x500mm | 2200mm | 11KW dual motor | 3890kg | 14500x500x2200mm |
7 Work stations | 1500mm | 880x500mm | 1700mm | 7.5KW dual motor | 4065kg | 12000x500x1700mm |
8 Work stations | 1500mm | 880x500mm | 1700mm | 11KW dual motor | 4614kg | 13500x500x1700mm |
1.There are many different kinds to meet your different needs
2.The source manufacturer has no middleman
3.Strict quality inspection rest assured of quality
4.Superior material, safe and reliable wear and tear resistance, long service life
