Hot Asphalt Plant Asphalt Batch Mix Plant in Ethiepia

Hot Asphalt Plant Asphalt Batch Mix Plant in Ethiepia

US$23,000.00-160,000.00 1 Set (MOQ)

Basic Info.

Type
Concrete Mixing Plant
Shotcrete Type
Semi-Dry
Machining Process
Welded Molding Machine
Structure
Spiral Type
Condition
New
Control
Central Computer Control
Loading
Optional
Overall Power
335kw
Production Speed
60~80t/H
Dust Removal Method
Water Dedusting/Bag Dedusting
Transport Package
Ocean Shipping
Specification
37*30*15/19m 110t
Trademark
ChenLi
Origin
Shandong, China
Production Capacity
30 Days/Piece

Packaging & Delivery

Package Size
1209.00cm * 235.00cm * 239.00cm
Package Gross Weight
26000.000kg

Product Description

Product Description
Asphalt batching plant, also called asphalt mixing plants or hot mix plants, are equipment that can combine aggregates and bitumen to produce asphalt mix for road paving. Mineral fillers and additives may be required to add to the mixing process in some cases. The asphalt mix can be widely applied for the pavement of highways, municipal roads, parking lots, airport expressway, etc.
Model LB-1000 LB-1500 LB-2000 LB-3000 LB-4000
Production capacity (tons/hour) 60~80 90~120 120~160 180~240 240~320
Cold aggregate bin capacity (m3) 8 8 10 14 16
Fuel consumption (kg/h) 518 800 1200 1800 2400
Bag filter filter area(m2) 338 474 577 880 1027
Measurement accuracy ≤±2.5% ≤±2.5% ≤±2.5% ≤±2.5% ≤±2.5%
Mixing tank output (kg/batch) 1000 1500 2000 3000 4000
Powder Elevator Flow Rate (tons/hour) 15 15 20 30 40
Total capacity of powder bin (single bin and double chamber) (m3) 30 30 40 50 62
Powder feeder flow rate (tons/hour) 30 40 60 85 110
Powder Screw Conveyor Flow Rate (tons/hour) 10 15 18 25 25
Total installed capacity (KW) 245 274 376 638 696

Working Principle
1. The height of the asphalt plant is reduced to within 15 meters, and is divided into the hot material silo building and the main mixing building. The hot aggregate is transported to the main mixing building via a lifting trolley (which ensures the accuracy of the proportioning and is better than the elevator structure) after measuring. The asphalt plant is centrally placed in the factory building in the industrial park to achieve industrialized production.
2. The asphalt plant is equipped with high-end environmental protection configuration. The discharging of dust, smoke and noise meets international environmental protection requirements.
3. High metering accuracy, short mixing cycle, and high output.
4. Ground warehouse type batching system, optional intelligent background feeding system.
5. Container modular design, integrated installation, convenient and quick installation and debugging.
Product Showcase
Company Profile
Tai'an Chenli Construction Machinery Co., Ltd. is a technology-based company focusing on the development, design, manufacturing, engineering and service of intelligent complete equipment for building materials. Based on a deep understanding of building intelligent equipment, Taian Chenli is committed to providing users with "practical, efficient, low-carbon, environmentally friendly, intelligent and advanced" intelligent equipment products. The products win the trust of the market with high standards and high reliability, and are deeply trusted by users.
Certification
FAQ
1. Do you offer warranty on your equipment?
Yes, we offer a full warranty on new equipment purchasing.
2. Where is the port of loading?
Normally the port of loading is QINGDAO PORT, SHANDONG, CHINA.
3. Can you print other LOGO on your machine?
Yes, we can, and we also offer OEM service.
4. Who are we?
We are professional manufacturer of concrete batching plant.
5. Where are you?
We are located in TAIAN City SHANDONG Province China.
