Microclimate Environment Detector, Environmental Detection Integrated Machine, Multifunctional Meteorological Weather Station Meteorological Air Detector

Product Description

Product Description The multi-element environmental detection integrated device is an IoT smart terminal product suitable for monitoring plant phenology, animal phenology, fire risk factors, and more. This product features an ultra-low power design and integrates multiple sensors, including atmospheric temperature, atmospheric humidity, dew point, light intensity, UV index, atmospheric pressure, wind speed, wind direction, rainfall, and pollutant particle concentration (PM2.5, PM10). It can operate using solar power and supports cloud access through NB-IoT, 4G, and LAN, without the need for human supervision. It boasts high integration, easy installation, flexible deployment, and long-term reliability.
Detailed Photos Main Functions
Element Monitoring
The system can monitor parameters such as atmospheric temperature, atmospheric humidity, dew point, light intensity, UV index, atmospheric pressure, wind speed, wind direction, rainfall, PM2.5 (optional), PM10 (optional), TVOC (optional), CO2 (optional), HCHO (optional), and more.
Data Reporting
Using an adaptive power algorithm, the data reporting interval can be variably adjusted (1-60 minutes adjustable).
Automatic Data Recovery
When the power supply is insufficient, the system automatically stops data reporting and saves the data locally. When the power supply is sufficient again, it automatically transmits the saved data.
IoT Networking
Supports multiple access methods such as NB-IoT, 4G, or RJ45, and various transmission protocols such as TCP/IP and CoAP.
Flexible Power Supply
All element models support solar power or mains power operation.
Product Parameters

Product Categories	nine elements	eleven elements
temperature	-40~+85ºC,accuracy±0.5ºC;
humidity	0~100%,accuracy±5%;
Illuminance	0~128kLux,accuracy±15%;
UV	1~11+,accuracy±1;
pressure	500hPa~1100hPa,accuracy±10hPa;
wind speed	0~35m/s,accuracy±0.5m/s ;
wind direction	0~360°,accuracy±10°;
rainfall	0~10mm/min,accuracy:±0.6mm;
dew point	0~+85ºC,accuracy±0.1ºC ;
PM2.5	None	0 ~ 500ug/m3, accuracy: ±15%;
PM10	None	0 ~ 500ug/m3, accuracy: ±15%;
communication mode	NB-IOT;
Power supply method	Solar power supply;
Work energy consumption	≤0.5W
working temperature	-20ºC~60ºC;
Working humidity	10-100%(No condensation)

Certifications
Company Profile Chongqing Yingka Electronic Co., Ltd., established in 2007, is located in the Erlang Overseas Student Pioneer Park, Jiulongpo District, Chongqing, China. The company is dedicated to the research and development of wireless sensor networks and AI technology, equipment, and systems for various applications in forestry, scenic areas, and power sectors. These applications include forest fire prevention, forest pest control, wildlife monitoring, bird monitoring, and ecological environment monitoring. Yinka Electronics has successfully overcome key challenges such as long-term field power supply, wireless networking in the field, and reliable low-power sensing. The company has undertaken the "National IoT Application Demonstration Project" by the National Development and Reform Commission and has accumulated over 10 years of experience in forest fire prevention and environmental monitoring applications.
Yinka Electronics is a provider of IoT application solutions for forest fire prevention and environmental monitoring in outdoor environments. It has provided applications and technical services to over 100 scenic areas, forestry, and power units across China.

Our Advantages 1. 16 years of experience in the production of IoT sensing devices
2. Experts in the IoT ecosystem industry
3. Collaborate with universities to establish a research team for expert academician workstations
4. Professional business personnel can respond online at any time
5. Comprehensive after-sales service
6. Customizable development and fast delivery
After Sales Service Online guidance and video tutorials for overseas buyers, with 24-hour online response
FAQ Q1: Are you manufacturer?A: (yes)Q2: What is the delivery cycle?
A: Usually one monthQ3: How do you ship the goods and how long does it take arrive?A: We usually ship by DHL, UPS, FedEx or by Air. 3-5 days after payment received.Q4: Can I have a sample order?A:Yes,we welcome sample order to test and check quality.Q5: Do you offer OEM service?A: Yes, we can design the things according to your request.
