CJK6132/1000 CNC Mini Lathe machine
| US$2,000.00-10,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
CJK6132/1000
Processing Accessory
pipe and flange type metal workpiece
Guide Rail
Horizontal Guide Rail
Tool Holder
4 Stations Tool Post
Power Source
Electric
Controlling Mode
CNC
Automatic Grade
Automatic
Setting Mode
Floor-type
Precision
High Precision
Certification
CE, ISO 9001
Condition
New
Swing Over Bed
320mm
Swing over carrage
150mm
Distance between center
1000mm
CNC system
Siemens
Transport Package
Veneer Box
Specification
CJK6132/1000
Trademark
HAVEN
Origin
China
HS Code
8466
Production Capacity
50 Units/Month
Product Description
CJK6132/1000 CNC Mini Lathe machineProduct Description
The machine can process precisely internal or external diameter, face, taper, arc and threading with high efficiency,Standard toolpost is 4-stations, also 6-stations toolpost can be optional selection,
Spindle speed changed by frequency,Induction harden bed-way. Bed saddle with plastic sticker can improve the accuracy and service life of the machine.
Main specification:
ITEM | CJK6132/500 | CJK6132/750 | CJK6132/1000 |
| Swing over bed | Φ 320mm | Φ 320mm | Φ 320mm |
| Swing over camiage | Φ 150mm | Φ 150mm | Φ 150mm |
| Distance between centers | 500mm | 750mm | 1000mm |
| Taper of barrel | M. T. 5 | M. T. 5 | M. T. 5 |
| Spindle hole | Φ 38mm | Φ 38mm | Φ 38mm |
| Range of speed(variable) | 100~2500r/min | 100~2500r/min | 100~2500r/min |
| Feed motor power(X/Z) | 6N. M/12N. M(Step motor) | 6N. M/12N. M(Step motor) | 6N. M/12N. M(Step motor) |
| X rapid traverse | 5m/min | 5m/min | 5m/min |
| Z rapid traverse | 10m/min | 10m/min | 10m/min |
| Max. travel of X axis | 160mm | 160mm | 160mm |
| Max. travel of Z axis | 500mm | 750mm | 1000mm |
| Motor power | 2.2Kw | 2.2Kw | 2.2Kw |
| Tool-post | 4 stations or 6 stations | 4 stations or 6 stations | 4 stations or 6 stations |
| Max. tool size | 16× 16mm | 16× 16mm | 16× 16mm |
| Min input unit | 0.001mm | 0.001mm | 0.001mm |
| repeatability accuracy(X/Y) | 0.01mm | 0.01mm | 0.01mm |
| Barrel travel of tailstock | 160mm | 160mm | 160mm |
| Barrel taper of tailstock | M. T. 3 | M. T. 3 | M. T. 3 |
| Packing size(L× W× H) | 1850× 1100× 1650mm | 1900× 1100× 1650mm | 2300× 1100× 1650mm |
| N/G Weight | 1800/2000kg(made of iron casting) | 1900/2100kg(made of iron casting) | 1200/1300kg(made of iron casting) |
| Loading amount | 6pcs/20' container | 6pcs/21' container | 5pcs/22' container |
