Quietest/Noiseless Ici Pilling and Snagging Tester Price Yg511-VI

Product Description

ICI Pilling and Snagging Tester Price YG511-VI
Application
Pilling and Snagging Tester. To determine the surface fuzzes and pilling properties of both woven and knitted materials.
Pilling is a fabric surface phenomenon characterized by little balls formed by entangled fibers clinging to the surface. These are formed during wearing or washing by the entanglement of the loose fibers, which protrude from the fabric surface, and development of these into spherical bundles anchored to the fabric by a few unbroken fibers. These give a very unsightly look to the garments. To determine the tendency to form pills, test specimens taken from the fabric sample are rubbed against each other under controlled conditions. The appearance of the test specimen, after rubbing for the specified period, is compared against standard rating photographs (Woven pilling photographs and knitted pilling photographs) for grading the fabric.
More models
YG511-II ICI Pilling and Snagging Tester - 2 boxes
YG511-IV ICI Pilling and Snagging Tester - 4 boxes
YG511-VI ICI Pilling and Snagging Tester - 6 boxes
YG511-IX ICI Pilling and Snagging Tester - 9 boxes
Standards
ISO 12945-1,BS 5811,IWSTM 152,NEXT 19,JIS L1076,M&S P18,M&S P21A,BS 8479,GB/T4802.3
Features
1. Specially designed equipment to access resistance to pilling of any type of fabrics as per ICI pilling system.
2. Six Pilling Boxes for better efficiency of work.
3. Microprocessor based controller with latest aesthetics.
4. 3.2mm Standard cork lining inside the boxes for proper pilling action.
5. Finest Quality Molded Polyurethane Pilling Tubes supplied (16Nos).
6. Specially designed standard size boxes meet the standard specifications.
7. Complete with all accessories-pilling tube, template,19 mm PVC Tape etc.
8. Smooth precision engineered components for excellent performance.
9. Innovative specimen-mounting jig saves efforts and reduces the chance of damage or distortion to the sample.
Specification

models	YG511-II		YG511-IV	YG511-VI		YG511-IX
Number of Pilling Boxes	2		4	6		9
Internal Dimensions	235×235×235mm
Rotational Speed	60±2r/min(40~80r/min)
Count Range	1~999999
Size of Test Specimen	Length 140 mm + 1 mm (As Per Standards) Diameter 31.5 mm + 1 mm Wall Thickness 3.2 mm + 0.5 mm Weight 52.25 52.25g
Power	AC220V 50Hz 120W
Weight(kg)	60	70			120	180
Dimensions(mm)	900×500×500	900×500×800			900×500×1100	1400×500×1600
