Multi Function CNC Metal 3015 Fiber Laser Cutting Machine Plate and Pipe 1.5kw-6kw

Product Description

H3015 Plate and Pipe Fiber Laser Cutting Machine
Product Description
1. Intelligent automatic focusing laser head
Automatic focusing mode of the laser head reduces human interference with a focusing speed of 10m/min and repeated positioning accuracy of 50um.
2. Aircraft-grade aluminum crossbeam
Aircraft-grade aluminum is corrosion resistant, lightweight and highly rigid, guaranteeing high speed laser cutting. Besides, it also guarantee the excellent cutting precision due to the perfect dynamic performance such as anti-twisting, anti-tilting and anti-deformation.
3. High quality thick wall carbon steel pipe welded bed
High strength machine bed is more stable and durable. After 600ºC stress relief annealing treatment, the machine bed has strong structural rigidity. The overall mechanical structure of the machine has small deformation, low vibration, ensure cutting accuracy.
4. Integrated large volume dust removal system
The dust removal system can remove all the smoke generated from the cutting process with large air volume. This helps protect the operator's health and the working environment.
5. Automatic lubrication system
Automatic lubrication method saves more human labor, reduces maintenance time, and greatly improves work efficiency.
Product Features 1. Sheet Cutting: The machine excels in cutting flat sheet materials, such as stainless steel, carbon steel, aluminum, copper, and more. It offers high cutting speeds, allowing for efficient processing of sheet metal components used in industries like automotive, aerospace, and manufacturing.
2. Tube Cutting: In addition to sheet cutting, this machine is equipped to handle various types of tubes, including round, square, rectangular, and oval shapes. It can cut tubes of different diameters and thicknesses, making it suitable for applications in industries like construction, furniture, and automotive.
3. Versatile Material Compatibility: A sheet and tube fiber laser cutting machine can work with a wide range of materials, including metals like steel, aluminum, brass, and copper. This versatility makes it an ideal choice for industries that require flexibility in their cutting processes.
4. High Precision Cutting: Thanks to its advanced fiber laser technology, the machine offers exceptional precision in cutting both sheets and tubes. It can achieve intricate designs and complex shapes with great accuracy, ensuring clean edges and minimal material waste.
5. Efficient and Productive: The combination of sheet and tube cutting capabilities in a single machine enhances productivity and workflow efficiency. It eliminates the need for multiple machines or manual switching, saving time and increasing overall production capacity.
6. Automated Operation: Many sheet and tube fiber laser cutting machines come equipped with automation features, such as automatic loading and unloading systems. This streamlines the cutting process and reduces reliance on manual labor, resulting in improved efficiency and reduced production costs.
7. Software Integration: The machine's software enables seamless integration with computer-aided design (CAD) and computer-aided manufacturing (CAM) systems. This enables precise programming and control of cutting parameters, ensuring accurate and consistent results.
8. Safety Features: As with any laser cutting machine, safety is a priority. Sheet and tube fiber laser cutting machines are equipped with safety enclosures, beam guards, and interlocks to ensure safe operation and protect operators from potential hazards.
9. Wide Range of Applications: The sheet and tube fiber laser cutting machine finds applications in various industries, including automotive, aerospace, construction, furniture, and manufacturing. It is used to create a multitude of components, parts, and structures with precision and efficiency.
Application
1. Automotive Industry: The machine is widely used in the automotive industry for cutting sheet metal components, such as car body parts, chassis components, and exhaust systems. It is also utilized for cutting tubes used in the fabrication of automotive frames and structures.
2. Aerospace Industry: In the aerospace industry, the machine is employed for cutting intricate sheet metal parts used in aircraft structures, engine components, and interior panels. It is also used for cutting tubes used in aerospace systems, such as fuel lines and hydraulic systems.
3. Furniture Manufacturing: The machine is utilized in the furniture industry for cutting sheet metal components used in the production of cabinets, shelves, frames, and decorative elements. It can also cut tubes used in the construction of furniture frames and supports.
4. Construction Industry: In the construction industry, the machine is used for cutting sheet metal components used in building facades, roofing systems, structural frameworks, and HVAC ducting. It can also cut tubes used in the construction of railing systems, handrails, and architectural features.
5. Manufacturing and Fabrication: The machine finds applications in general manufacturing and fabrication processes. It is used for cutting sheet metal components for various industries, including electronics, machinery, appliances, and signage. Additionally, it can cut tubes used in the fabrication of frames, supports, and custom structures.
6. Energy and Power Generation: The machine is utilized in the energy and power generation sector for cutting sheet metal components used in the production of renewable energy systems, power transmission equipment, and heat exchangers. It can also cut tubes used in the construction of pipelines and conduits.
7. Agricultural Equipment: In the agricultural industry, the machine is used for cutting sheet metal components used in the fabrication of farming equipment, such as tractors, harvesters, and irrigation systems. It can also cut tubes used in the construction of agricultural machinery frames and supports.
8. Medical Equipment: The machine finds applications in the medical industry for cutting sheet metal components used in the production of medical devices, hospital equipment, and surgical instruments. It can also cut tubes used in the construction of medical equipment frames and supports.
9. Sports and Recreation: The machine is utilized in the sports and recreation industry for cutting sheet metal components used in the production of exercise equipment, sporting goods, and outdoor structures. It can also cut tubes used in the fabrication of bicycle frames, fitness equipment, and recreational vehicle components.

Parameters

Model	HM-3015
Working area	1500*3000mm
Optional Working Area	1300*2500mm, 2000*3000mm, 2000*4000mm, 2000*6000mm,..
Configuration	Specifications
Laser Generator	Max/Raycus/IPG
Laser Cutting Head	Au3tech, Raytool,
CNC Controller	Au3tech, Cypcut
Servo driver system	Delta/Yaskawa/Pansonic
Speed Reducer	Shimpo Reducer, Japan
Rack and Pinion:	Taiwan CSK/TBI/HIWIN guide rails
Max.cutting speed	0-30m/min(Depending on the material and thickness)
X, Y, Z Axis Repeat PrecisionX, Y, Z Axis Repeat Precision	≤±0.03mm /m
Min line width	≤0.15mm
Maximum Empty Running Speed	120m/min
Driving way	Imported servo motor
Transmission way	Y-axis import gear rack double driver, X-axis imported ball screw
Cooling System	Water Cooling
Continuous working time	24 Hours
Power requirements	380V/3 Phases /50Hz or 60Hz

Product Details
Raycus/Max/IPG Laser Source
Most famous laser source brand in China.
Fiber laser is compact in structure, stable in performance and widely used, Fiber laser has high photoelectric conversion efficiency, good beam quality and low maintenance cost.
Muitiple choice different power brand, and different power are available. The higher power , thicker cutting thickness.
Tube welded Bed The constant temperature of water chiller can keep the laser power stable,work more stable and fast
Which is welded by a number of rectangular tubes. Stiffeners are arranged inside the tubes to increase the strength and tensile strength of the bed, it also increases the resistance and stability of the guide rail so as to effectively avoid the deformation of the frame.
High strength, stability, tensile strength, ensuring 20 years of use without distortion; Thickness of rectangular pipe wall is 10mm and weight is 2000kg.
Aluminium Gantry
High hardness Aerospace aluminum is manufactured with aerospace standards and extruded in a 4,300 ton press. The hardness can reach T6 after processing.
High speed Aviation aluminum has the features like good toughness, light weight, corrosion resistance, oxidation resistance and low density, which greatly improve the processing speed.
Laser Head
Including: Manual Focusing and Automatic Focusing,More and more fiber laser cutting machine use automatic focusing laser head.
The software automatically adjusts the focusing lens to realize automatic perforating and cutting plates of different thickness.
The speed of automatically adjusting focus lens is ten times of the manual adjusting.
Bigger Adjustment Range
Adjustment range -10 mm~ +10mm, precision 0.01mm, suitable for 0 ~ 20mm different types of plates.
Long Life Time
Collimator lens and focus lens both have water-cooling heat sink which reduces the temperature of the cutting head to improve the life of the cutting head
Japan Yaskawa servo motor and drive
-More accurate
It realizes closed-loop control of position, speed and torque; overcomes the problem of stepping motor out of step;
-Rotating speed is more faster
High speed performance, general rated speed can reach 2000~3000 rpm;
-Daptability
High strong anti-overload capability, load three times the rated torque, suitable for occasions with transient load fluctuations and fast start required;
-Stable
Smooth operation at low speed, no stepping operation similar to stepper motor when running at low speed.
Tube Cutting Part
16-25mm machine bed is cut from whole steel panel with heat and aging treatment, milled by Italy machining center with high precision, good stability, no deformation; the bed will be put in furnace to heat to 600 degree and keep temperature to 200 degree for a week and then be taken out for cooling naturally. The process takes about 15-20 days.
Samples Show
Our service
1. For whole fiber laser cutting machine, we provide 2 years warranty and lifetime after-sales service, we will provide the consumable. parts at an agency price when you need replacement.
2. Main parts(excluding the consumables) shall be changed free of charge if there is any problem during the warranty period.
3. Our engineer could support you technology to your country if necessary.
4.Our engineer could service you 24 hours online by Skype, WhatsApp, msn, or by cellphone.
5. English manual and CD video for machine using and maintaining will send to you with the machine.
