Single Extrusion PE PP Lamination Machine Coating Machine

Product Description

HT-1000/1200/1500/1600/2000 Single layer or Double-layer extrusion
Double shafts Roll Changing /Intelligent Temperature Control
Extrusion Laminating Machine for non-woven fabric,paper ,aluminum foil coating
USE:
This machine is Casting Lamination Compounding Machine,can accept LDPE,PP...etc lamination grade material,Use for non-woven, EPE, woven bags as base material for compounding lamination.it processes by melting the plastic for extruding form the T die mould and finally laminating with the base material, this type of machine has been widely used for the lamination of substrates such as paper, non woven fabric, non woven fabric, woven fabric, aluminum foil, BOPP film etc. The finished product is famous for its high fastness, uniformity of thickness and high sealed capability, all these have contribute of make this type of machine become one of the most popular and valuable extrusion laminating machines in domestic market and abroad.Widely used in office packaging,industrial packaging and other packaging.

Model	HTLM-1000	HTLM-1200	HTLM-1600
Max lamination width	1000	1200	1600
Diameter of screw	80mm	90mm	100mm
Motor power	30kw	37kw	45kw
Extrusion capacity	100kg/h	160kg/h	200kg/h
Suitable resin material	LDPE, PP
Suitable basic material	Paper (35-350g/m2) non woven fabric, woven fabric, aluminum foil
Mechanical speed	80-150m/min
Coating thickness	0.012mm-0.05mm
Unwinding diameter (step)	1200mm
Unwinding diameter(frictional)	1200mm
Auxiliary unwinding diameter	450mm-600mm
Tension, inverter	Full automatic tension controller, digtal vector control
Electric controller mode	PLC+touch screen

Finished Roll And Application
Company Information
RUIAN HENGTUO MACHINERY CO.,LTD. located in Ruian City, Zhejiang Province,China.is an innovative enterprise which integrates packaging machinery with professional scientific research and development, design and manufacturer, sales and after-sales service.
Main products: Three layer co-extrusion stretch film making machine, Double extruder stretch film making machine, single extruder stretch film making machine, bubble film making machine, compound bubble film making machine, film blowing machine, printing machine, bag making machine etc.
Packaging & Shipping
1.Machine will be tested before shipping
2.Packing: If shipped FCL,stretch film wrapping with anti rust treatment;If shipped LCL,stretch film wrapping with anti rust treatment,wooden case packege.
Our Services
1.Installation Services
Installation Services are available with all new machine purchases. We will provide the technical know-how for your operation smooth transition and support for installing, debugging, operation of the machine, it will indicate you how to use this machine well.
2.Clients Traning Services
We can train your staff to use your film blowing equipment systems properly. It means that we offer Customers Training, teaching how to use the systems most efficiently and safely as well as how to maintain optimal operational productivity.
