TBTCTM-2000A Concrete Strength Compression Testing Machine with PC Control

Product Description

TBTCTM-2000A Compression Testing Machine with PC Control Product Description
TBTCTM-2000A is a semi-auto high-precision compression machine which applies loading on specimen driven by hydraulic system. Computer makes close-loop control, automatic measuring, data acquisition and processing. The test accuracy is better than 1st grade. The applied loading, timing and test curve are controlled & displayed in PC real time, the peak loading will be hold to avoid electric blackout.
Product Parameters

Model	TBTCTM-2000A
Maximum Capacity	2000 kN
Measuring range	2-100% full range with no grading
Accurate display	Grade 1
Relative Error	±1%
Loading rate control range	0.2~10 kN/s
Columns	4
Distance between columns	290 mm
Platen size	220*290mm
Max. Vertical clearance between platens	330 mm
Maximum travel of piston	40 mm
Diameter of piston	Ф250 mm
Dimension	910*400*1200mm
Power supply	220VAC 750W

Packaging
Business Fields
Company Profile
NANJING T- BOTA SCIETECH INSTRUMENTS& EQUIPMENT CO., LTD
Established in year 2008 as one professional pavement equipment supplier, TBT dedicates to porvide testing equipment forengineering project and laboratory use. Our proudcts includes asphalt testing equipment, concrete testing equipment, cement testing equipment, mental testing equipment, non-mental tesing equipment, soil testing equipment and universal testing equipment, etc. We can provide complete set of testing equipment for your engineering projects such as highway, railway, cement factory, bridge and building.
TBT company is a global supplier and has built its business worldwide. Since its inception, TBT has continued to enhance its products, services and all relevant business activities. After more than a decade of development, we have established complete product supply chain. Every year, we will dispatch professional technical teams to visit the supply chain of each our product to ensure its quality and cost performance. If we find the product has any quality issues, we will terminate the cooperation with the manufacturer.
Due to our strictly control of the supply chain, our products are always the combinations of quality and economy. Our products have been sold to many countries and regions including Southeast Asia, Middle East, Africa, Europe and America, etc. Recent years, the importance of road, pavement and highway safety get high awareness in China and all other countries. Testing for raw material of pavement, inspection& maintenance of road, pavement and highway will help improve the lifetime of roads and pavement, meanwhile prevent accident; TBT nowadays is working hard on these fields to make contribution on this aspect.
FAQ
1. How long is the delivery time?
Normally goods will be shipped out within 7-10days after contract signed and down payment received.
2. Is it possible to make our own brand/logo on your product?
Yes, but depends on MOQ.
3. What's your MOQ?
This depends on different types of products. If it is a large machine, the MOQ is usually 1 set. For small instruments, such as thermometers, the MOQ is 50 pieces.
4. What kind of payment term you accept?
Normally,
1) If total contract value less than USD 10,000.00 : 100% T/T in advance after contract signed.
2) If total contract value more than USD 10000.00 : 50% T/T in advance after contract signed and 50% T/T after receipt of BL copy. Or, irrevocable LC is acceptable.
