US$13.00-15.00
|
100 Pieces
(MOQ)
|
Basic Info.
Model NO.
KLT-K3MF-OV9714 V1.1
Specification
66.00 x 11.00 mm
Production Capacity
500000 Pieces
Product Description
1MP OV9714 MIPI-Schnittstelle Fester Fokus Kameramodul
Kameramodul Nr. KLT-K3MF-OV9714 V1.1
| Kameramodul Nr. | KLT-K3MF-OV9714 V1.1 |
| Auflösung | 1MP |
| Bildsensor | OV9714 |
| Sensorart | 1/4" |
| Pixel Größe | 3.0 um x 3.0 um |
| EFL | 3.29 mm |
| F.NO | 2.80 |
| Pixel | 1296 x 816 |
| Betrachtungswinkel | 68.7°(DFOV) 58.1°(HFOV) 45.0°(VFOV) |
| Linsenabmessungen | 8.00 x 8.00 x 4.97 mm |
| Modulgröße | 66.00 x 11.00 mm |
| Modultyp | Fester Fokus |
| Schnittstelle | MIPI |
| Autofokus-VCM-Treiber-IC | Keiner |
| Linsenmodell | KLT-LENS-M5101 |
| Linsentyp | 650 nm IR-Schnitt |
| Betriebstemperatur | -30°C to +85°C |
| Gegenstecker | AXE540124 |
