Jiujiang Xinxing ECG75 2/3 Electrical Yarns Twisted Yarn

Jiujiang Xinxing ECG75 2/3 Electrical Yarns Twisted Yarn

US$2,000.00-2,500.00 1 Ton (MOQ)

Basic Info.

Model NO.
ECG75 2/3(EC9 68x2x3)
Yarn Structure
Single Yarn
Surface Treatment
Vinyl Coated
Fiberglass Type
E-Glass
Province
Jiangxi
City
Jiujiang
Brand
Xinxing
Packing
2kg Paper Bobbin
Twist
28~150
Sizing Agent
Paraffin
Quality
Best
Original
Jiujiang City, Jiangxi Province
Transport Package
Cartons or Pallets
Specification
43.5MM*32.7MM*32.3MM
Trademark
XINXING
Origin
China
HS Code
7019130090
Production Capacity
15000t/Year

Product Description

Item Code:
ECG75 2/3(EC9 68x2x3)

Specification:
1) Fiberglass yarn use glass sphere as raw material
2) It is insulation, high intensity,corrosion resistance, high temperature resistance,low water absorption,etc.
3) It is necessary material of all kinds of insulation products and industry yarn.
4) Specification:6tex,12tex,27tex,33tex,normally1-strand,2strand,3strand,4strand,6strand,8strand
5) Other specification can be produced per customers requirments

Technical Parameter
Specification Product Type (British System) Density
(tex)
Linear Density
(μm)
Strand NO.* Strand Strength(N/TEX) Twist of Yarn
Customizable Twist
Direction of Twist
EC9 68x1 G75 1/0 68±4 9 68x1 ≥0.50 28~100 101~150 Z
EC9 68x1x2 G75 1/2 136±8 68x2 28~150 151~280 S
EC9 68x2x2 G75 2/2 272±20 68x2x2 28~150 151~280 S
EC9 68x2x3 G75 2/3 408±28 68x2x3 28~150 151~280 S
EC9 68x2x4 G75 2/4 544±38 68x2x4 28~150 151~280 S

Packaging Information
Type of Yarn Tube Units of Measurement Package Capacity Carton Type Carton Capacity Packing Size
(L*W*H)
4kg(plastic tube) SI(cm) 3kg Carton+ 120 1282*1124*1035
2kg(paper tube) SI(cm) 1.8kg Carton+ 12 43.5*32.7*32.3
8kg(plastic tube) SI(cm) 7.6kg Carton+ 66 1282*1124*1035

Storage and Transportation
Products are mainly packaged in cartons.It is recommended to maintain room temperature balance, and the optimal storage conditions are 15~35ºC.This product should be kept in the original packaging before use, in order to ensure safety and avoid damaging the product, the layer height is not more than six layers.The mode of transportation is wagon consignment,and the packaging is pallets and wrapping film

Product Application
Electronic grade glass fiber cloth is mainly used for copper clad substrate, insulation board, insulation cloth, fireproof cloth, engineering plastic reinforcement, etc.
Delivery Time:
(1) Payment trems:
With T/T or L/C
30% of payment in advance, the balanced 70% should be paid when the copy of B/L at sight.
(2) Lead Time:
within 7-15 working days
(3) Port:
Fob Jiujiang or Shanghai
We are offering you different kinds of glassfiber yarn which with best quality and competitive price,most of our products was pupolar with more than 10 countries from Asia and Europe such as Germany,Italy,Russia,Estonia,Japan .etc. If you are interested in our products and need more detailed information about our goods and prices,please contact us asap.
We sincerely hope to cooperate with you.
