Sintered Stone CNC Cutting Machine Stone Processing Machine Automatic CNC Cutting Machine with Optimized System

Product Description

Product Description
Detailed Photos
Waterproof countertop
Specially developed 6mm thick 6061 high-strength pre-stressed industrial aluminum beams to ensure the service
life and load-bearing capacity of the aluminum beams. The large-scale milling machine processes the mounting
surface to ensure the verticality and straightness of the mounting surface and improve accuracy.
Co-developed cutting system with Shanghai Weihong and Shenzhen Gogo, which has the advantages of small
footprint, long service life, stable performance, etc. The optimization rate can reach 99%.
High-definition industrial explosion-proof screen, aluminum alloy profile shell, explosion-proof, dust-proof,
ultra-long service life and ultra-wide viewing angle.
Product Futures:
1. The absolute value motor and imported high-precision racks and other top components can effectively
ensure the accuracy and stability of glass cutting, and have a longer service life, which can meet
the cutting of various shapes of glass and sintered stone;
2. One-piece guide rail, exclusive patent, higher cutting precision;
3. The machine is made of waterproof, fireproof, high and low temperature resistant, and anticorrosive materials,
which will never be deformed;
4. Infrared scanning point function and infrared scanning special-shaped template function;
5. Highly intelligent cutting machine optimization software, which greatly improves the utilization rate of raw materials
and reduces production costs;
6. Air flotation function, improve work efficiency, with automatic feeding machine and separator;
7. The automatic oil injection and automatic pressure adjustment function of the cutting machine can effectively
ensure the cutting stability and cutting effect;
8.No special requirements for operators, simple operation and easy management.
Product Parameters

Compressed air	0. 6-0.8Mpa
Glass size	MAX. 2440*2000
Glass thickness	3-15mm
Cutter head speed	0~200m/min (can be set)
Cutting bridge speed	0~200m/min (can be set)
Cutting acceleration	>8m/s²
Cutting knife holder	The cutter head can rotate 360 degrees (precisely cut straight lines and special shapes)
Cutting accuracy	<±0. 2mm/m (subject to the size of the cutting line before breaking the film)
Voltage	380V,50Hz
Power	7.5KW
Dimensions	5600*2000*1630mm

Certifications
Packaging & Shipping
Company Profile
Shandong Huashil Automation Technology Co., LTD., is a set of mechanical equipment automation research and development, manufacturing, sales in one of the high-tech manufacturing enterprises,mainly research and development production of a full set of glass deep processing intelligent equipment,such as the glass loading and cutting machine,glass cutting line,glass shuttle warehouse intelligent chip trimming system,glass edging machine,glass double-sided edging machine and so on.
We have wealth mechanical automation equipment production experience, production capacity, technological level and comprehensive economic strength in the same industry in the forefront of the domestic industry, intelligent automation equipment research and development, material control, equipment performance and modeling has been in the domestic leading level, a number of techniques. have filled the domestic blank. The good after - sales service and reasonable price, for a long time to win the customer's praise. In line with the principle of "good faith first, customer satisfaction", our company has established long-term cooperative relations with many enterprises.Huashil colleagues will be positive,open mind to meet new opportunities and challenges, we always been to use science and technology into productivity for the mission, to help China's economic development.

FAQ
Q: Are you manufacturer or trading company?
A: We are manufacturer of glass deep processing line for about 10 years .
Q: Do you provide install training and after-sale service?
A: Yes, we supply install service on line or send our engineer to your country to help you install and adjust machines before and after your sale .
Q: Can you produce as customer's requirement ?
A: Yes, we can manuacture as your customized.
