Factory ANSI/GOST/Duplex/ Ss/CS /Weld Neck Slip on/Blind/Threaded/Socket Weld/Plate/Spectacle Blind/Lwn/Orifice/Anchor Flange
| US$50.00-2,000.00 | 1 Piece (MOQ) |
Basic Info.
Material
Carbon Steel
Structure
Flanges
Connection
Welding
Sealing Surface
FF
Manufacturing Way
Forging
Class
150lbs to 3000lbs
Materials
CS /Ss /Alloy /Stianless Steel
Face Type
FF/RF/Wn/So/Th/Lj/Bl/Sw etc
Pressure
150lb, 300lb, 600lb, 900lb, 1500lb, 2500lb, 3000lb
Wall Thickness
Sch5-Sch160, Xxs
Produce Type
Forging/Casting
Certificate
SGS/ISO9001
Shipment
by Sea or by Air
Delivery Time
Within15days
Usage
Connect Pipes or Fittings
Painting Color
Black/Yellow/Transparent Paint
Package
Pallet, Wooden Case, as Customers Requir
Original
China
Flange Surface
FF RF FM Rtj
Design
Welding Neck, Slip on, Blind, Socket Weldi, Thread
Transport Package
Wooden Box
Specification
1/2"to 80" and DN10-DN3600
Trademark
VKING
Origin
China
HS Code
7307910000
Production Capacity
1000ton/Month
Product Description
Factory ANSI/GOST/Duplex/ Ss/CS /Weld Neck Slip on/Blind/Threaded/Socket Weld/Plate/Spectacle Blind/Lwn/Orifice/Anchor FlangeFlange technical parameters:
| Type | weld neck flange, slip on flange, blind flange, tube sheet, threaded flange, socket weld flange, plate flange, spectacle blind, LWN, Orifice flange, anchor flange. |
| OD | 15mm-6000mm. 1/2"to 80".DN10-DN3600 |
| Pressure | 150#-3000#,PN0.6-PN400,5K-40K,API 2000-15000 |
| Standard | ANSI B16.5,ANSI B16.47 A/B, EN1092-1, SABA1123, JIS B2220, ALL DIN, ALL GOST, ALL UNI, AS2129, API 6A , BS4504, etc |
| Wall thickness | SCH5S, SCH10S, SCH10, SCH40S,STD, XS, XXS, SCH20,SCH30,SCH40, SCH60, SCH80, SCH160, XXS and etc. |
| Stainless steel | A182F304/304L, A182F316/316L, 316H, 321H,304H, 310H, A182F321, A182F310S, A182F347H, 347L, 317L, A182F316Ti, A182 F317, 904L, 1.4301, 1.4307, 1.4401, 1.4571, 1.4541 etc. |
| Carbon steel | A105, A350 LF1,A350LF2,A350LF3, Q345, E24, A42CP,A48CP, A515 GR55, A515GR60, A515GR70, A516 GR60, A516 GR70, ST37.2,ST45.8, Q235, STEEL20, P235GH,P245GH, P250GH, P265GH, P280GH, P295GP etc. |
| Duplex steel | UNS31803, SAF2205, UNS32205, UNS31500, UNS32750 , UNS32760, 1.4462, 1.4410, 1.4501, A182F51, A182F53 and etc. |
| Pipeline steel | A694 F42, A694F52, A694 F60, A694 F65, A694 F70, A694 F80 etc |
| Nickel alloy | inconel600, inconel625, inconel690, incoloy800, incoloy 825, incoloy 800H ,C22, C-276, Monel400, Alloy20 etc. |
| Cr-Mo alloy | A182F11, A182F5, A182F22, A182F91, A182F9, 16mo3 etc. |
| Application | Petroleum industry, Refinery Company, fertilizer industry, power station, shipbuilding, onshore platform |
| Attention | ready stock,faster delivery time;available in all sizes,customized;high quality |
Flange type:
Flange Applications:
Water works, shipbuilding industry, petrol chemical & gas industry, power industry, valve industry,and general pipes connecting projects etc.
