New Condition Electro Magnet Still Plate Lifting Magnet for Steel Works

Product Description

√ Effortlessly elevate either single or multiple bunches of steel bars or rebars in one seamless motion, ensuring efficiency and robustness in every lift.
√ Enjoy unparalleled lifting support, even when dealing with steel featuring minor deformation disturbances.
√ With its substantial magnetic permeability depth, this system offers exceptionally stable adsorption, setting a new standard in reliability.
√ The motor seamlessly adjusts the beam's length without interfering with surrounding objects, providing flexibility and precision.
√ Proudly holding our proprietary patent certificate, Patent Number: ZL201020522632.1, a testament to our innovation and industry leadership.
Product Description
Unveiling Electro Permanent Magnetic Technology
Electro permanent magnet technology ingeniously uses electricity to manipulate permanent magnet material's magnetic field lines. This innovation creates either a magnetic force (magnetized state) or a non-magnetic force (demagnetized state), allowing for precise control over material attraction or release.
In the Magnetized State, an electromagnetic coil uses instantaneous excitation current to toggle the magnetic field of reversible magnetic material, unleashing powerful adsorption forces over the magnetic poles' surface. This closed-loop magnetic field boasts zero loss, operating silently, without heat emission or energy consumption, as illustrated in Figure 1.1.
In the Demagnetized State, another burst of instantaneous excitation current alters the reversible magnetic field, converging it within the permanent magnet and ceasing field presence on the magnetic pole surface, thus releasing the material, as depicted in Figure 1.2.
About Electro Permanent Magnet
Combining robust safety with innovative design, the Electro Permanent Lifting Magnet System is immune to power outages or short circuits, eliminating the need for auxiliary UPS systems. It requires no electricity during operation, as its formidable suction is powered by permanent magnetic materials. This ensures that materials remain securely adsorbed, only to be released upon demagnetization, providing unparalleled safety for the user.
Advantages of Electro Permanent Magnet:
1. Economical, Energy-Efficient, and Environmentally Friendly
The electric permanent magnet system only requires electricity during the brief phases of magnetization and demagnetization. It consumes over 95% less power compared to traditional electromagnets, with no operational power or temperature increase, drastically cutting costs.
The considerably lighter weight of both the lifting permanent magnet and control system reduces the burden on lifting equipment, enhancing load capacity.
2. High Security
Harnessing magnetism from two distinct types of permanent magnetic materials, this system achieves a commanding maximum magnetic force of up to 16kgf/cm². It operates independently of electrical power, eliminating risks associated with sudden power failure or cable damage, and maintains magnetic intensity without degradation over time, ensuring top-tier safety.
3. User-Friendly Operation
With simple electronic control featuring only charge and demagnetization buttons, this system ensures ease of use, completing magnetization or demagnetization within 0.1-1 seconds, significantly boosting operational efficiency. The permanent magnet system is devoid of wear and tear components, hydraulic oil, or compressed air, requiring no special maintenance, just basic surface cleanliness for reliable and durable use.
Once demagnetized, the residual surface magnetic force is virtually nonexistent, preventing any small magnetic particles from adhering to the magnetic pole surface. This guarantees a scratch-free adsorption process with no residual buildup.
4. Unique and Adaptable Product Design
The internal structure of the lifting permanent magnet boasts an innovative modular design, incorporating dual magnetic source technology. This is a groundbreaking approach in product manufacturing, with a uniquely configured internal framework that sets this product apart.
5. Comprehensive Functionality
The Electro Permanent Lifting magnet system epitomizes safety with its independence from power loss—no auxiliary UPS battery system required. It harnesses the enduring power of permanent magnetic materials, ensuring a consistent and reliable grip. This guarantees that demagnetization is only possible when materials are safely grounded, offering ultimate security for end users.
Electro Permanent Lifting Magnet VS Electromagnet

SEQ	Compare Content	Electro Permanent Lifting Magnet	Electromagnet
1	Magnetic	Permanent magnet Material: Reversible magnet steel,	Electricity: Magneticfield generated by Currentthrough the coil
	source	fixed magnet
2	Principle	The magnetic field is turned on or off by an	Power on generated magnetic field, power off no magnetic field
	mechanism	instantaneous current
3	Security	All steel surface, oil&water-proof, no aging issue	Epoxy resin sealed, may occur aging and shedding issue in5
			years later, need repair.
4	Reliability	The suction is constant and does not attenuate over time	Suction is influenced by the heat caused by current, the coil is
			easy aging if use long time.
5	Durability	Permanent magnet no magnetic attenuation, magnetic
	and	module is maintenance-free.	Internal coil aging fast, the UPS battery need to be replaced
	maintenance		regularly, need to preparethe accessories.
6	Operating	Only in the moment of magnetization and	Need long-term electricity power during working, big power
	costs	demagnetization need electricity, no need power	consumption, commonly known

Packaging & Shipping
Electro Permanent Magnet System Composition (Standard)
1. Electro Permanent Magnet
The core component of magnetic force, facilitating direct contact and adhesion to the work piece.
2. Control System (including sound and light indicator system)
Handles the processes of magnetization/demagnetization, and manages the collection and processing of all signals.
2.1. Long-Distance Controller (optional)
Mini control cabinet designed for use in Crane Cab or other confined locations.
2.2. Remote Controller (optional)
Mini control cabinet designed for use in Crane Cab or other confined locations.
3. Cable Retracting Device
Designed to efficiently manage cable movement, pulling in and out via reel for seamless release and collection.
4. Beam
Facilitates the collection and transmission of permanent magnet tension.
