Jewelry Label 8.2MHz EAS RF Label Supplier

Jewelry Label 8.2MHz EAS RF Label Supplier

US$0.01
10,000-2,999,999 Pieces
US$0.0074
3,000,000+ Pieces

Basic Info.

Model NO.
QDRL018
Application
Video Store and Bookstore, Warehouse, Shopping Arcade, Supermarket, Garment Store, Jewelry Store
Detection Signal
Radio Frequency RF
Certification
CE, ISO, RoHS
Frequency
8.2MHz
Detect Distance
0.9-1.2m
Model No.
Qdrl018
Printing Type
EAS RF Jewelry Label
Color
Black/White
Quality Control
4 Test During The Production Before Delivery
Diameter
30*30mm
Packing Details
1000PCS/Roll, 20000PCS/CTN
Carton Size
40X30X23cm
Gross Weight
10kg
Delivery Time
5 Days After Deposit Received.
Warranty
2 Years Warranty From The Date of Delivery, a Life
Transport Package
1000PCS/Roll
Specification
RoHs, SGS, CE, ISO
Trademark
QIDA
Origin
Guangzhou Guanddong
HS Code
85319010
Production Capacity
60000000PCS Per Month.

Product Description

Jewelry Label, RF Labels, Store Security Stickers, RF Soft Label Manufacturer
Detailed Product Description

Label Dimension Specification

Diameter
40mm (1.31')

Thickness(including liner)
27μm

Thickness(excluding liner)
21μm

Label Spacing
2mm (0.066')


Material Specifications

Substrate
80g/m2 glassing paper

Surface
80g/m2 thick reinforced paper

Inductor Side
Aluminum

Capacitor Side
Aluminum

Adhesive
Rubber-based, hot melt adhesive


Electrical Specifications

Frequency
8.2MHz±328KHz

Amplitude
Q≥70

Effective Volume
≥2000cm3

Deactivation Strength
0.9A/m-1.5A/m

Operating Distance
1.4m-1.7m

Deactivation Distance
25cm-30cm (0.82'-0.98')



Environmental Specifications

Shelf Life
Two years from date of manufacture when labels are stored between 10ºC-25ºC (50ºF-77ºF) and 35% to 65% RH

Temperature
Maximum storage temperature not to exceed 50ºC (120ºF) for 96 hours at 80% RH

Humidity
Unaffected by 80% humidity up to 96 hours

Application Temperature
Above 0ºC-38ºC (32ºF-100ºF) and 90% RH at the application head
Recommended ambient temperature is 15ºC-32ºC (60ºF-90ºF)
Recommended ambient humidity is 50%-70%


Roll Specifications

Labels Per Roll
1000 labels
2000 labels

Roll Length
42m (137.8')
84m (275.6')

Diameter Inner Core
7.6cm (3'')
7.6cm (3'')

Roll Outer Diameter
13.4cm (5.3'')
18.5cm (7.3'')

Roll Weight
0.47kg (1.04lb)
0.91kg (2.0lb)

Case Weight
9.8kg (21.6lb)
9.4kg (20.8lb)

Rolls Per Case
20
10

Case Dimension
27cmx27cm
x23.5cm
(0.89' x0.89'x0.77')
32cmx32cm
x23.5cm
(1.05' x1.05'x0.77')


Why Choose us?
1. One-stop security solution Supplier, can be help you to save time and costs.
2. Our own manufacturer could strictly control the quality, and make the cost to be the most competitive one.
3. Easy opration, attractive design.
4. Professional technique supports and great service.
5. Fast delivery and safe shipping way.
6. Providing excellent protection for your merchandize.
Shipping Method:
1) Fast delivery: By Express courier, such as DHL, TNT, FedEx, UPS and EMS
2) Cheap way: By air or by sea shipment.
Quality Warranty:
1 - 2 years warranty from the date of delivery, a lifetime technical support.
